Walk through metal detector (XST-LCD)
Door Frame Metal Detector, Metal Detector,Security Metal Detector
Features:
- Easy to operate with the big LCD screen, Chinese & English operate language
Infrared remoter controller adopted - Made of high quality alloy and PVC synthetic material, Watertightness and fireproofing.
- Six detecting zones which overlapped each other are as tall as examinee, combine with alarm-LED on every zone. Show the position of target metal directly.
- Four emitters match with receivers opposite, eliminate detecting blind spots.
- Sensitivities can be adjusted: Each zone's sensitivity can be adjusted from 0 to 99. You can select the right sensitivity you want. For example you can change the sensitivity to avoid inferences such as the coins, keys, buckle, etc.
- The function of statistics: The number of passed examinees and the alarm times can be count.
- Parallel operation: The gate can not only work itself, but also work together with the same model (when parallel operate, the distance between each unit must more than 40 cm), so that it can meet the demand of big visitor flow rate.
- No harm to people: The gate is harmless to people with cardiac pacemakers, pregnant women, tapes, videotapes, etc.
- Installed conveniently: Integrated design, you can assemble or disassemble it in 20 minutes with the operation instruction.
- Protected by password: Only the authorized person can operate it.
- Location signal display light: Display the responses of each zone apart (independent of alarm lights). Adjust the sensitivity of each zone according to the responses, and get the best sensitivities.
| Technical parameters | |
Power Supply |
220V/AC |
Power |
<30V |
External Dimension |
2200mm(H)*820mm(W)*550mm(D) |
Passageway Dimension |
2000mm(H)*700mm(W)*550mm(D) |
Work environment |
-20°C- +45°C |
Standard |
GB15210-2003<WALK THROUGH METAL DETECTOR> |
Standard Configuration | |
Main Case |
ONE Unit |
Left Probe |
ONE Unit |
Right Probe |
ONE Unit |
Power Line |
ONE Unit |
Screws |
Eight Unit |
Instruction |
ONE Unit (Including one Certificate of Quality & Guarantee Repair List) |
Accessories Purchased
Slipping groove: Let the personal belongings which may be interference (such as keys, watches, cell, etc) slip through.
Remote Control: Control the gate within 10 meters, when paralleled the distance should be short.
Storage Battery: Maintain the gate working for about 4 hours after charged.
1. Places which should be security examined. Such as airport, customs, harbor, station, etc.
2. Places where prohibited metal items should be examined. Such as court, police station, jail, lockup, etc.
3. Public places entrances Such as important place, exhibition, business rally, celebration meeting, stadium, etc.
4. Industries where the valuable metal articles should be avoided missing. Such as hardware, electronics, jewelry, coinage line , etc.
5. Entertainment places where dangerous items should be forbidden. Such as nightclub, theater,
ballroom, bar, KTV, etc.
6. Places where the dangerous items should not be taken with, such as the Bank , Government , Post office, school , private house ,etc.
Examining Standard
Electrical Equipments standardized by EN60950.
Radiation standardized by EN50081-1.
Anti-inference standardized by EB50082.
Execute the standard of National Standard of Metal Detector
PS: Coin Standard: The gate can detect one coin with out inference.
Warranty:
(2)All Products have been well packed before shipping
(3)One Year warranty is proviced for all models. we will bear maintenance cost during warranty period.
(4)OEM Service ofference
Design service offered
Buyer label offered
T/T, Western Union, Moneygram ,Escrow,Paypal
1 year warranty for all kinds of products;
If you find any defective accessories first time, we will give you the new parts for free to replace in the next order, as an experienced manufacturer, you can rest assured of the quality and after-sales service.
Transportation:
Shenzhen XinSaiTong Technology Company Limited is a high-tech enterprise, professional for designing, manufacturing, marketing, XST engineering, electronic security equipment on Security porducts.
Our Vision: Spread our band with high quality products, take the market with high quality products, competitive price and best after sale service, enlarge the company with invition. We keep updating and improving our products and developing new products to meet all the needs.
Our main products : handheld metal detectors, walk through metal detectors, under vehicle search mirrors and underground search metal detectors, X-ray inspection system and EAS. And our main markets are Eastern Europe, South America, North America, the Middle East, Africa and Southeast Asia. Until now, we have exported our products to more than 80 countries and districts .
Our products are widely recognized and trusted by lots of companies. We aim to achieve a win-win cooperation. We are waiting for you!
Q1: How To Order
A: Step 1, please tell us what model and quantity you need;
Step 2, then we will make a PI for you to confirm the order details;
Step 3, when we confirmed everything, can arrange the payment;
Step 4, finally we deliver the goods within the stipulated time.
Q2: When will make delivery ?
A: Delivery Time
-Sample Order: 1-3 days after receipt of the full payment.
-Stock Order: 3-7days after receipt of the full payment
-OEM Order: 12-20days after receipt of the deposit.
Q3: Do you support drop shipping?
A: Yes,your drop shipping is available.
