Flat Pressurized Solar Water Heater System(150L, 200L , 250L ,300L, 500L )
US$ 90 - 500
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Evacuated Tube
Pressure:
Pressurized
Circulation Type:
Indirect / Closed Loop (Active)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fashionable Outlook Solar Flat Panel Collector(JSFP-L02)US$ 200 - 700MOQ: 1 Set -
Blazonry Flat Plate Pressurized Solar Water HeaterUS$ 80 - 360MOQ: 1 Set
-
Compact Flat Panel Solar Water HeaterUS$ 500 - 1,500MOQ: 1 Set
-
Pressurized Flat Panel Solar Water HeaterUS$ 500 - 1,500MOQ: 1 Set
-
Pressurized Flat Panel Solar Water HeaterUS$ 500 - 1,500MOQ: 1 Set
Type
Evacuated Tube
Pressure
Pressurized
Circulation Type
Indirect / Closed Loop (Active)
Heating System
Thermosyphon (Passive)
Connection Type
Direct-Plug
Installation
Freestanding
Housing Material
Other, color steel
Certification
CE, Other, CE, RoHS, CCC SGS ISO9001
Capacity
300
Place of Origin
Zhejiang, China
Brand Name
Jishen
Model Number
JS-FP-A01
Specifications
Flat Pressurized Solar Water Heater System(150L, 200L , 250L ,300L,500L )CE CCC SGS RoHS ISO9001
Blazonry and environmental
Flat Pressurized SolarWaterHeater System( 150,200L , 250L ,300L, 500L )
Product Information:
| Product specification of flat panel: | |
| Size(LxWxH mm) | 2000x1060x70/80/90(mm) |
| Total area of collector | 2 M2 |
| Daylighting area | 1.85 M2 |
| Absorbing area | 1.85 M2 |
| Material of cover glass/thickness(mm) | low-iron tempered patterned glass/4.0mm |
| Absorbancy | ≥ 97% |
| Pipe port material /size | complete copper / Φ25x950mm |
| Pipe material/size | complete copper / Φ10x1950mm |
| Number of riser pipe | 7/8/9 bars |
| Absorber fin/thickness(mm) | copper/0.2mm |
| Absorber coating | blue sputtering selective coating |
| Insulation materials /thickness | high-density fiberglass board/50mm |
| Back sheet | 0.3mm galvanized steel plate or 0.5mm embossed alumimum plate |
| Material of frame / thickness | Anodized aluminium alloy(silver and black color) /90mm |
| Operation pressure | 1.0MPa |
| Test pressure | 1.6MPa |
| Working temperature | -34 ≤T≤200 centidegree |
