Flat Pressurized Solar Water Heater

Flat Pressurized Solar Water Heater photo-1
US$ 80 - 800 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Flat-Plate
Pressure:
Pressurized
Circulation Type:
Indirect / Closed Loop (Active)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Type Flat-Plate
Pressure Pressurized
Circulation Type Indirect / Closed Loop (Active)
Heating System Thermosyphon (Passive)
Connection Type Split
Installation Wall Mounted
Housing Material Other, Color steel
Certification CE, Other, CE, RoHS, CCC SGS ISO9001
Capacity 150
Place of Origin Zhejiang, China
Brand Name JISHEN
Model Number JS-FP-A09

Specifications

Flat pressurized solar water heater
CE CCC SGS ISO9001 RoHS
Blazonry,green,environmental and fashionable for home use



Flat pressurized solar water heater



solar panel collector,solar flat plate,flat panels solar collectors,pressurized solar flat panel,flat panel solar water heater


Size(LxWxH mm) 2000x1000x70/80/90(mm)
Total area of collector 2 M²
Daylighting area 1.85M²
Absorbing area 1.85M²
Material of cover glass/ thickness(mm) float glass/toughened glass/low-iron ultra white tempered patterned glass/4.0mm
Absorbancy ≥92%
Pipe port material /size complete copper / Φ25x950mm
Pipe material/size complete copper / Φ10x1950mm
Number of riser pipe 7 / 8 / 9bars
Absorber fin/thickness(mm) copper/aluminum(0.15-0.5mm)
Operation pressure 1.0Mpa
Test pressure 1.6 Mpa
Insulation materials /thickness high-density fiberglass board/3050mm
Back sheet 0.3mm galvanized steel plate or 0.5mm embossed alumimum plate
Material of frame / thickness Anodized aluminium alloy(silver and black color) / 70/80/90mm
Material of bracket stainless steel/galvanized steel/aluminium alloy
Working temperature -34≤T≤200

Inner tank material:SUS304-2B stainless steel 1.5mm thickness,food grade,innocuity.

Outer tank material:galvanized steel 0.33-0.55mm thickness,antirust.

Insulation layer between inner and outer tank:High density polyurethane foaming,50-65mm thickness.

Water tank capacity:300L

Bracket material:galvanized steel,1.5mm thickness.

The glistening obliquity:45 degree

Hail resistance:25mm.

Wind stress:180km/h

Heat preservation:72-96HOURS
