Beautiful and Powerful Compact Flat Panel Solar Water Heater With Stainless Steel
US$ 300 - 500
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Flat-Plate
Pressure:
Pressurized
Circulation Type:
Indirect / Closed Loop (Active)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
300L Efficient Compact Flat Solar CollectorUS$ 150 - 999MOQ: 5 Sets -
2012 Hot Sale Flat Solar CollectorUS$ 500 - 1,500MOQ: 10 Sets
-
Flat Solar CollectorUS$ 560 - 1,100MOQ: 3 Sets
-
Flat Pressurized Solar Water HeaterUS$ 80 - 800MOQ: 1 Set
-
Flat Pressurized Solar Water Heater System( 200L , 250L ,300L, 400L,500L )US$ 100 - 600MOQ: 1 Set
Type
Flat-Plate
Pressure
Pressurized
Circulation Type
Indirect / Closed Loop (Active)
Heating System
Batch / ICS (Passive)
Connection Type
Direct-Plug
Installation
Freestanding
Housing Material
Other, Stainless Steel, stainless steel
Certification
CE, Other, CE, RoHS, CCC,ISO9001,SGS
Capacity
200
Place of Origin
Zhejiang, China
Brand Name
Jishen
Model Number
JSFP-L010
Specifications
1. 10 years warranty!2.CE,SGS,CCC,ROHS certificates
3.beautiful apparentness
4.good enough water pressure
Compact Flat Panel Solar Water Heater Specification:
| Size(LxWxH mm) | 2000x1000x70/80/90(mm) | ||||||
| Total area of collector | 2 M2 | ||||||
| Daylighting area | 1.85 M2 | ||||||
| Absorbing area | 1.85 M2 | ||||||
| Material of cover glass/ thickness(mm) | float glass/toughened glass/low-iron ultra white tempered patterned glass/4.0mm | ||||||
| Absorbancy | ≥92% | ||||||
| Pipe port material /size | complete copper / Φ25x950mm | ||||||
| Pipe material/size | complete copper / Φ10x1950mm | ||||||
| Number of riser pipe | 7 / 8 / 9bars | ||||||
| Absorber fin/thickness(mm) | copper/aluminum(0.15-0.5mm) | ||||||
| Operation pressure | 1.0 Mpa | ||||||
| Test pressure | 1.6 Mpa | ||||||
| Insulation materials /thickness | high-density fiberglass board/3050mm | ||||||
| Back sheet | 0.3mm galvanized steel plate or 0.5mm embossed alumimum plate | ||||||
| Material of frame / thickness | Anodized aluminium alloy(silver and black color) / 70/80/90mm | ||||||
| Material of bracket | stainless steel/galvanized steel/aluminium alloy | ||||||
| Working temperature | -34≤T≤200 | ||||||
Water Tank Details:
Inner tank material: SUS304-2B stainless steel 1.5mm thickness,food grade,innocuity.
Outer tank material: Stainless steel 0.35mm thickness,antirust.
Insulation layer: High density polyurethane foaming, 50mm thickness.
Water tank capacity:200L
Bracket material: galvanized steel,1.5mm thickness.
The glistening obliquity: 45 degree
Hail resistance: 25mm.
Wind stress: 180km/h
Heat preservation: 72Hours.
