Turning and Milling Center

Name: Turning and Milling Center
Brand: TOSUNNY
SKU: 107291129
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Other, Turning Center, Turning and Milling Center

CNC or Not:

CNC

Contact Supplier Request Quote Chat Now

Taizhou Taisen Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Other, Turning Center, Turning and Milling Center

CNC or Not CNC

Place of Origin Zhejiang, China

Brand Name TOSUNNY

Model Number HTM54103

Voltage 380V

Certification ISO

After-sales Service Provided No overseas service provided

Turning and Milling Center

HTM54103 milling & turning center is a combined CNC machine tool with high accuracy and high rigidity. It is equipped with five axes in X, Y, Z, B and C, which can machine simultaneously. This machine adopts international advanced ATC single spindle turret with rapid swivel and accurate repeatability, as well as tool magazine and changing-tool robot. The changing-tool robot is of ram structure with simple and reliable control. The rotation of tool magazine is driven by servo motor in high speed and high stability, It is suitable for machining complex components of vanes and camshafts.

specification	HTM54103
On the largest diameter rotary bed	540mm
Diameter of the largest processing	540mm
Turning the greatest length	1030mm
X/Y/Z axis trip	485/140/1055mm
B/C shaft	205/360°
Spindle power / torque (nominal)	18.3/350kW/Nm
Before diameter spindle bearings	140mm
Via spindle diameter	73mm
Spindle first models	A2-8
Chuck spindle diameter	254mm
Tailstock body trip	590mm
Tailstock diameter / itinerary	100/130mm
Tool maximum torque spindle	100Nm
The maximum tool spindle speed	7000r/min
Bearing motor torque B	14.7Nm
Tool storage capacity	20Put
Maximum length Tool	250mm
Maximum size of the installation tool	25×25mm
Tool-to-tool tool change time	2s
The largest hole diameter	30mm
Tapping the largest diameter	M22mm
Maximum diameter rod cutter	40mm
Diameter of the largest Endmills	80mm
X/Y/Z fast axial velocity	30/15/20m/min
X/Y/Z/C/B axis positioning accuracy	0.012/0.012/0.02mm
X/Y/Z/C/B axis repetitive positioning accuracy	0.006/0.006/0.008mm
C/B axis positioning accuracy	40"/±4"s
C/B axis repetitive positioning accuracy	28"/±1.5"s
Precision Machining	IT6
Surface roughness	Ra1.6μm
Weighing machine	7500kg
Machine dimension(L×W×H)	4000/2450/2800mm
NC system	SIEMENS840D
