Help CenterMilling Machine
US$ 10,000 - 15,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
tosunny
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Zhejiang, China
Brand Name
tosunny
Model Number
Xk7130A
Type
Other, Vertical, milling machine
CNC or Not
CNC
Voltage
380V
Dimension(L*W*H)
1540*1340*2130mm
Weight
1300kg
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Specification
Specification |
Unit |
XK7130A |
X-axis travel |
mm |
460 |
Y-axis travel |
mm |
210 |
Z-axis travel |
mm |
360 |
Spindle nose to table |
mm |
120-480 |
Spindle center to column guide-way face |
mm |
200-500 |
High speed feeding of X,Y axis |
mm/min |
3000 |
Feeding speed |
mm/min |
1-2000 |
Size of working table |
mm |
1000×280 |
Max.loading capacity of rotary table |
mm |
100 |
T-slot NO./width/distance of rotary table |
3×14×63 |
|
Spindle speed range/step |
r/min |
66-4540/16steps |
Main motor rated power |
Kw |
2.2(3HP) |
Spindle hole taper |
7:24 ISO30 |
|
N.W |
KG |
1300 |
Overall dimension |
mm |
1540×1340×2130 |
