1t 3t 5t 6t 8t 10t 15t 20t 25t Plate Ice Machine
- 100 Set / Sets per Month
- Fuzhou
- T/T L/C D/P D/A Credit Card PayPal
- New York slide valve displacement sensor 534D1251H01, maintenance of lubrication system malfunction for turbine compressor
- New shaft seal 534M0163G02, York TDSH193 compressor disassembly and maintenance parts
- 200kg Dry ice pellets making machine for dry ice production
- New York Liquid Flowmeter 024W26116-002 Flow Switch HF68 Mechanical Target
- New slide valve potentiometer coupling 111Q0451313
- New Kunteng 5 motherboard 649C1152G01 York FRICK circuit board 649C1158G01
Product Details
Condition: | New | Capacity: | 25t/day, 1t 3t 5t 6t 8t10t 15t 20t 25t per day | Place of Origin: | Fujian, China |
Brand Name: | CSCPOWER | Model Number: | P250 | Ice Shape: | Other, plate ice |
Voltage: | 220V 240V 380V 400V 415V 440V | Power(W): | 5.25kw | Dimension(L*W*H): | 1900*1650*1700, all available |
Weight: | 890kg | Certification: | CE | Warranty: | 15 Months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Product Description plate freezer
cold room cold storage refrigerator freezer
Aluminum alloy contact freezer is composed of Plate evaporator, Electrol Cabinet, Hydraulic Pressure device etc. The Aluminum alloy evaporator is driven by hoist cylinder to contact with frozen foods directly and keep certain pressure. The closed touch, with frozen food forms advantages of high frozen speed, high efficiency energy-saving, sanitation and c ompact. The unit is running under normal temperature to ensure long-ter m life. Adopt contact-type heat conducting, no air flow, which is benefit to decrease foods weight loss.
The Aluminum alloy is complete stainless steel machine housing,attractive appearance,easy cleaning an operation.Electromechanical integral design,less investment is aso very conveienct on installation and operation.
Basic Data of the Machine | |
In-take Temp: | +15°C |
Out-take Temp: | -18°C |
Ambient Temp: | ≤50°C |
Condensing temp: | +35°C |
Evap. Temp: | -35°C |
Refrigerant: | R22, R404A, R717 or similar. |
Freezing Time: | Fish: 2-4h/shift, (tray size: 600*400*80mm, 15kg/tray) Shrimp: 2-3h/shift, (tray size: 300*200*70mm, 2kg/tray) Codfish: 2.5h/shift, (tray size: 520*310*60mm, 7.5kg/tray) |
Required Information for Choosing the Contact Freezer
1. Frozen product name
2.Frozen product size (L×W×H mm)
3.Frozen product unit weight (“g/pc”, or “g/box” mentioning box material)
4.Freezing capacity (ton/h)
5.Product inlet temperature and outlet temperature(°C)
6.Installation room space (L×W×H mm)
7.Required freezer type(fully contact/semi-contact/marine plate freezer)
SCOPE OF APPLICATION
The unit is widely applied in cold storage, aquatic foods, meat processing foods quick freezing industry, fish catching boat and fishery processing industry etc.
Model | Evaporation Plate | Frozen Fish | Frozen Prawn | Frozen Codfish | Dimensions (L*W*H) (mm) | Weight (Kg) | ||||||
Effective Layer | Spacing of Each Layer (mm) | Effective Dimension (mm) | Evaporating Area (m2) | Frrozen Capacity (Kg/Time) | Consumption(Kw) | Frrozen Capacity (Kg/Time) | Consumption(Kw) | Frrozen Capacity (Kg/Time) | Consumption(Kw) | |||
PZ(Y)-720-B1 | 8 | 58~108 | 1290*1260 | 30 | 720 | 23 | 384 | 15 | 480 | 22 | 2540*1750*2350 | 2300 |
PZ(Y)-720-B2 | 2710*1750*1685 | 2400 | ||||||||||
PZ(Y)-960-B1 | 8 | 58~108 | 1680*1260 | 40 | 960 | 31 | 512 | 20 | 720 | 33 | 2960*1750*2350 | 2700 |
PZ(Y)-960-B2 | 3130*1750*1685 | 2800 | ||||||||||
PZ(Y)-1200-B1 | 10 | 58~108 | 1680*1260 | 49 | 1200 | 39 | 640 | 24 | 900 | 41 | 2960*1750*2710 | 3000 |
PZ(Y)-1200-B2 | 3130*1750*1945 | 3100 | ||||||||||
PZ(Y)-1500-B1 | 10 | 58~108 | 2080*1260 | 60 | 1500 | 48 | 800 | 30 | 1200 | 54 | 3370*1750*2790 | 3600 |
PZ(Y)-1500-B2 | 3540*1750*1945 | 3700 | ||||||||||
PZ(Y)-1950-B1 | 13 | 58~108 | 2080*1260 | 76 | 1950 | 63 | 1040 | 39 | 1560 | 70 | 3370*1750*3305 | 4200 |
PZ(Y)-1950-B2 | 3540*1750*2339 | 4200 | ||||||||||
PZ(Y)-1980-B2 | 11 | 58~108 | 2530*1260 | 78 | 1980 | 64 | 1056 | 40 | — | — | 3780*1750*2950 | 4250 |
PZ(Y)-2520-B2 | 13 | 58~108 | 2530*1260 | 91 | 2520 | 81 | 1344 | 51 | — | — | 3780*1750*3305 | 4900 |
The Products with special type can be designed and manufactured according to the requirement of the customer.The specifications are the frozen goods consumption without water.The pictures are for reference only,the styles can be made to order! |
