Product Details
Place of Origin: | Henan, China | Brand Name: | ZS | Model Number: | X-mas Tree |
Product Description
Wellhead Equipment& X-mas Tree Zhongshi
Production introduction:
Christmas tree Wellhead and Christmas tree equipment is an important oil and gas mining equipment, from the casing head, tubing head, oil (gas) tree consists of three parts, used to connect casing string, tubing string and sealing layers between the casing and the annular space between the tubing and to control the pressure and regulate the production wellhead oil (gas) wellhead flow, can also be used for acid fracturing, water, testing and other special operations. The Christmas tree is the assembly of the valve and the accessories, which is used for the fluid control of the oil/gas well, and supplying the inlet for the tubing string. The Christmas tree refers to all the devices on the tubing head and the flange.Christmas tree could be assembled differently so as to meet the different requirements. The Christmas tree could be used for oil exploration, gas exploration, water adding, compression fracture, acidification, etc. The different Christmas trees are with the different pressure grades.
The Christmas tree and the tubing heads are mainly used for gas exploration and adding. Because the natural gas is with the low relative density and adding pressure, while the wellhead is with the high pressure and flow rate, it would be easy to leak. Sometimes, there’s H2S, CO2 and other corrosive medium in the natural gas. It would have the more strict requirements on the sealing capacity and the sealing materials of the Christmas tree. Thus, the tube and the sleeve should be with double valves. The valves should be forged by the best-quality steel for the high-pressure or extra-high-pressure gas well.
specification
1 API Spec 6A standard.
2 To fix drilled wellhead, connect wellhead casing string, seal and control the annular space of casing, suspend tubing, control wellhead pressure and adjust flow rate, induce oil into outlet pipeline, shut off oil wells when necessary and apply to acid fracturing, water injection and testing services.
3 Consisting of casing head, tubing head and Christmas tree.
4 Applicable to all kinds of casing and tubing programs and connection types.
5 Reliable running and simple and convenient operating and repairing.
6 Can be equipped with hydraulic/pneumatic safety valves.
7 High quality and good pre/post-sale services.
8 Packaging: applicable for land/air/marine transportation or as required.
API 6A Wellhead X-mas Tree or Christmas tree Our Christmas tree have been ISO9001 certified and attained API 6A approvals of American Petroleum Institute.All products are fully designed and manufactured in accordance with API,ANSI,GB(national standance)and SY(industry standards)standards. Fix drilled wellhead, connect wellhead casing string, seal and control the annular of casing, suspend tubing, control wellhead pressure and adjust flow rate, also include oil into outlet pipeline, shut off oil well when necessary, and apply to acid fracturing, water injection and test service. Consist of casing head, tubing head and Christmas tree. Apply to all kinds of casing, tubing programs and connection forms. Feature reliable running, simple and convenient operating and repairing. Can be equipped with (pneumatic) hydraulic safety valve.
Working pressure: 2000PSI~20000PSI
Working medium: oil, natural gas, mud ,including H2S,CO2
Working temperature: -46°C~121°C(Class LU)
Material class: AA,BB,CC,DD,EE,FF
Specification level: PSL 1-4 Performance level: PR 1-2 < Standard Operating Pressure Operating Media Operating Temperature Material Grade
Specification Level Performance Level ND (in/mm) Colour API Spec 6A 2000-20000psi Oil/ Natural Gas/ Mud/ Water/ Gas containing H2S/CO2 LU (-46℃- 121℃) AA BB CC DD EE FF HH PSL1-4 PR1-2 2 9/16" 7 1/16'' 65-180 Red or as required
Puyang Zhongshi Group Company Ltd was founded in 1996,which is the restructured enterprise of Central Plains oilfield branch company of SINOPEC . The company registered capital is 6083 million yuan,with annual output value 200 million yuan, 580 employees, including more than 160 technical and administrative staff. Oil machinery is our main products, the leading products include pumping unit,subsurface sucker rod pump, wellhead (Christmas Tree), pressure vessels,drilling solid control series products and cementing accessories, We had attained ISO 9001 in 1998 and API Certificates in 2002 .
All products purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free. Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will assign technical personnel to solve your problems immediately after receiving telephone and hear feedback idea of users and deal with them in time. If you are caught in some problems when using our products, welcome to contact us at any time.
