650L Tractor High Pressure Power sprayer (3WZ-650)

Specifications

1.Simple gear structure
2.Big flow and good efficiency
3.650liter capacity
4.Many spray nozzles
5.Mating power >=50HP

Wheeled Power Sprayer



Specification  High pressure power sprayer,Four stroke power sprayer wheeled power sprayer





Model	3WZ-650
Flow(L/min)	80
Tank Volume (L)	650
Tank materail	PE
Work pressure(Mpa)	0.2-0.4
Mating Power	>=50HP(rear out)
Spray width(m)	12
Nozzles(pcs)	24
Net.Weight(kg)	64
Effciency(m3/h)	>=26600





This machine adopts gear structure to decrease speed and the structure is simple and has high pressure, big flow and good efficiency.

The main spraying parts are 24 nozzles, which are developed and only adopted by our factory in our country. So the spraying range is wide.
