FDG6740FX School Bus Price

FOB Price

Negotiable / Unit

1 Unit(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

L*W*H: 7370*2360*2950mm
Gross weight: 7100kg
Standard passenger seats: 35+1+1
With good quality and best price.

FDG6740FX School Bus Specification

Overall Parameter

Overall Length (mm)	7370
Overall Width (mm)	2360
Overall Height (mm)	2950
Wheelbase (mm)	3935
Front/Rear Overhang (mm)	1040/2395
Approaching/Departure Angle (°)	24/6
Front/Rear Tread (mm)	1750/1600
Max. weight (kg)	7100
Rated Passenger Capacity	35+1+1
Top Speed (km/h)	80

Engine Parameter

Model	YC4FA130-40
Manufacturer	YUCHAI
Position/Fuel type	Front/ diesel
Type	Inline ,4 strokes, water-cooling ,turbo-intercool,electricity control.
Max Power (kw/r/min)	95/3200
Max Torque (N.m/r/min)	340/1600-2400
Displacement	2.982 L
Emission Standard	Euro IV

Chassis Parameter

Model	NJ6711YFD10
Gear box	TC5-40 manual five speed with synchro.
Clutch	single dry type, Driven disc diameter φ330, Hydraulic remote control, Power assist
Front Axle	Forged module, “H”type section, two fist-end type 2.4T
Drive Axle	Integrate instructions 5 T Speed radia: 4.8757
Suspension	Leaf spring 9/8
Steering	Power steering, steering wheel diameter φ450
Brake	Dual circuit air brake with ECE standard,,air brake , Front Disc & Rear Drum braking.
Oil Tank	85L
Tyre	8R17.5-10PR
Battery	135Ah×2/100A 28V
Others	ABS, copper water tank
