Detailed configuration of articulated bybrid city bus for sale
Overall Parameter
| Overall length (mm) | 11650 |
| Overall width (mm) | 2480 |
| Overall height (mm) | 3390 |
| Wheel base (mm) | 5700 |
| Front/rear overhang (mm) | 2630 / 3320 |
| Approach/departure angle(°) | 7/7 |
| Front/rear overhang (mm) | 2040 / 1860 |
| Gross weight(kg) | 17500 |
| Rated passengers | 79 / 24-42 |
| Top speed (km/h) | 75 |
Engine Parameter
| Engine model | YC6J190N-40 |
| Manufacturer | Yuchai |
| Position /fuel | Rear/CNG |
| Type | Inline ,4 strokes,water-cooling turbo-intercool, electricity control |
| Max power (kw/ r/min) | 140 / 2500 |
| Max torque (N.m/r/min) | 650/ 1500 |
| Displacement | 6.5L |
| Cylinder ×bore (mm) | 105x125 |
| Emission standard | Euro IV |
Chassis Parameter
| Chasis /Manufacture | WZL6123DPHEVGER Chongqing Wuzhoulong |
| Main Motor No./Manu. | YPQ220L-6M (75KW) / Dalian Tianyuan zai |
| Battery No./Manu. | HEV336V100Ah / Guangdong Power Technology Co., Ltd. Wuzhou Long |
| Cluth | φ395 , Electric control ,single .dry style , diaphragm spring |
| Front Axle | Dong feng 6.5T , Forged module, “H”type section, two fist-end type |
| Driving axle | Single-grade reduction, hyperbolic gear |
| Suspension | 5/5 Leaf spring 5/5 |
| Steering | Power steering |
| Brake | Dual circuit air brake with ECE standard,drum brake |
| Gas cylinder | (8*80L) 640L |
| Tyre | 275/70R22.5 6pcs |
| Battery/Generator | 165A.h×2/110A +140A 28V |
| Body structure | Semi Monocoque |
| Inner decoration |
Integral moulding intenerate interior trim, Yellow spray roller spend handrails, Hang Ring 16 pcs |
| Door & door pump | Front double inner-swing, rear double inner-swing passenger door ,pneumatic Pump. |
| Windshield&side window | Whole view laminated front windscreen/ Adhesive side window, sliding side window at rear. |
| Review system | Rod rearview mirror,Inner Mirror ,Monitoring for down&up. |
| A/C | Guangzhan A/ Ccool cap.30000Kcal/h.Roof style . |
| Heating system/ | Water heating defrost system |
| Video& audio system | MP3 |
| Lamp | Integral Front & Rear combination lamp; |
| Wiper | Opposite type wiper with detergent |
| Seats | Injection Molding with soft cushioning Pubic city bus seats . Adjustable driver seats |
| Floor leather | Anti-slipping chinese floor leather |
| Lacquer | Solid lacquer |
| Others |
Extinguisher, (4Kg×2), 2 auto distinguishers in engine compartment. froth rail ,Half driver sun-visor, 4 Safety hammers , Front & Rear luminescence Road Line, Air filter access door, Colorful Rearing Monitor, Electric Clock, gas control system. |
At present, the international business has covered more than 40 countries and regions.Products are exported to Middle East, South America, Africa, Russia and Europe and the United States and other high-end market, and has been in Chile, Hong Kong, Macao, Sudan, Syria and other countries and regions established after-sales service network, and 2011 in the united Arab emirates sign a sole agency.
With our service policy---support from maintainer,easily damaged parts and spare parts.Wuzhoulong warranty is to ensure excellent performance of Wuzhoulong bus.So service as bellow would be supplied:
1.According to the quality,certain senior maintainers(5 or above working experience) would be dispatched to the export country to take charge of maintenance at spot,technology training and aftersales service.
2.For the large quantity,a service network consisting of service station and spare parts warehouse would be established.
3.For every export bus,one set of easily damaged parts in value of RMB5000 for free and one list of parts and their prices for 3 years long would be supplied.
4.Each order would be supported with a series of free advertising things.Including well-illustrated catalogs,CDs and so on.
5.According to the policy on bus maintenance,maintenance for CBU is 80 thousand kilometers or one year,and the one for engine is 180 thousand kilometers or one year,subject to the one which reaches the requirement firstly.
