WZL6950NG4 CNG City Bus for Sale

Name: WZL6950NG4 CNG City Bus for Sale
Brand: Wuzhoulong
SKU: 107166667
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Seats:

21 - 40

Emission Standard:

Euro 4

Transmission Type:

Manual

Chongqing Wuzhoulong New Energy Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Seats 21 - 40

Emission Standard Euro 4

Transmission Type Manual

Max Speed 51 - 70 km/h

Steering Position LHD

Fuel Type Gas / Petrol

Dimensions (L x W x H) (mm) 9500*2480*3150mm

Place of Origin Chongqing, China

Brand Name Wuzhoulong

Model Number WZL6950NG4

Specifications

Dimension: 9500*2480*3150mm
Curb weight: 13000kg
Rated Passenger: 60/28+1
Engine: YC6J190N-40
Emission Standard: Euro IV

Specification

Overall Parameter
Overall length (mm)	9500
Overall width (mm)	2480
Overall height (mm)	3150
Wheelbase (mm)	4450
Front/rear overhang (mm)	2170/2880
Approaching/Departure Angle(°)	9°/10°
Front/Rear Tread (mm)	2030/1800
Max. Weight(kg)	13000
Rated Passenger	60/28+1
Top Speed(km/h)	ECU system will control the engine so as to limited speed within 60

Engine Parameter
Engine model	YC6J190N-40
Engine manufacture	YUCHAI Engine
Engine position/fuel	Rear /CNG
Engine type	Inline, 6 cylinders, water cool, 4 stroke
Max Power (ps/r/min)	190HP/2500(140KW/2500)
Max Torque (N.m/ r/min)	650/1500
Displacement (L)	6.5
Emission Standard	Euro IV

Chassis Parameter
Model	NJ6897chassis
Gear box	QJ705
Clutch	φ395 single, dry. Diaphragm spring clutch. Hydraulic remote control
Front Axle	Forged, “H”type section, load 5T
Drive Axle	Intergrade forged axle, Load 9T, speed ratio 6.33
Suspension	Leaf spring F/R 5/6
Steering	Power steering, steering wheel adjustable up and down, φ500.
Brake	ECE standards, dual-circuit pneumatic, drum braking.,Snuff brake, front brake φ400x150 rear brake φ400x180, Brake steam room specifications:F 24’’, R 30’’, whole vehicle brake valve use Wabco brand valve.
CNG cylinders	Total 470L the cylinders bottom fixed, with cylinder protection device
Tyre	11R22.5(10 holes) 7pieces
Motor /battery	200Ah×2/150A 28V
Others	Automatic slack adjuster arm.
