6m Mini Inner City Bus WZL6661GT4

Name: 6m Mini Inner City Bus WZL6661GT4
Brand: Wuzhoulong
SKU: 107166637
Availability: InStock

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Seats:

16 - 30

Emission Standard:

Euro 4

Transmission Type:

Manual

Chongqing Wuzhoulong New Energy Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Shenzhen port

Delivery Detail:

Delivery time depends on order quantity.

Seats 16 - 30

Emission Standard Euro 4

Transmission Type Manual

Condition New

Engine Capacity 4 - 6L

Fuel Type Diesel

Place of Origin Chongqing, China

Brand Name Wuzhoulong

Model Number WZL6661GT4

Specifications

Dimenssion: 6640x2260x2770mm
Emission: Euro IV / III
Seater: 19

Chongqing Wuzhoulong Bus

Overall Parameter
overall length (mm)			6640
overall width (mm)			2260
overall height (mm)			2770/2950
wheelbase (mm)			3300
Front/Rear overhang (mm)			1220/2120
approach angle/ departure angle (°)			20/15
front/rear tread (mm)			1750/1600
gross weight(kg)			6500
rated passenger			33/10-25
(km/h) ECU limited speed (km/h)			69
Engine Parameter
engine model		YC4FA115-40
engine manufacturer		YULIN
engine position/ fuel		front/ diesel
engine type		Inline cylinders,4 strokes ,water-cooling ,turbo-intercool,
max power(ps/r/min)		85/3200
max torque(N.m/ r/min)		300/1600-2400
displacement(L)		2.982
emission standard		Euro. IV
Chassis Parameter
chassis model /manufacturer	EQ6570K4AC1
transmission	Manual five files with synchronizer
clutch	single dry spring , Driven plate diameter φ325 ,Hydraulic long-distance manipulation ,gas power
front axle	''H" section forged modeling , 2200kg
driving axle	''H" section forged modeling , 4200kg
suspension	More pieces of steel plate spring (front9 /rear 11), level 3 step
steering	power steering
braking	Accord with standard double loop ECE air brake
fuel tank	85L
tyre	7.00-16 6pieces
charging / generation	105Ah×2/100A 28V
