220V 60Amps Battery Testing/battery Load Tester/battery Discharger Real Capacity Tester

General:

220V Battery Load Bank is specifically designed for the maintenance of the lead-acid battery discharge in the electricity sector. It is a new high-tech intelligent product that provides safe, reliable and convenient constant testing equipment for the DC system

Product Type:

Different discharge current range

All above listed items are standard one. The voltage and currency can be customized according to client’s certain demand. When you place order please indicate the voltage, currency, model and function as well as if you need single section supervision by wire or wireless.

Main Functions and Features:

Used to discharge to battery string removed from the system

Discharge to Battery string voltage as 220V, Cell voltage as 1.2V/2V/6V/12V

4 adjustable stop points and multiple alarm designs to control the discharge process intelligently

7inch LCD touch screen for easy operation and showing various parameters real time

Support RS232 real time monitoring by PC or SD Card download data after discharge

PC software for capacity evaluation and report generation

Optional wireless modules for 1.2V/2V/6V/12V cells voltage real-time measuring

On-line monitoring setting:

Online monitoring for battery string: when the battery string is under the state of online discharge, uniform charge and floating charge, perform real-time online monitoring for all cells. The monitoring includes string voltage, cell voltage, discharge current, monitoring time of battery string, charge/discharge capacity of battery string and etc.

2. Discharge Setting:

The instruments can analyze according to main test function on the histogram and the curve chart. It’s unnecessary to upload the result in PC.

Providing data management, print, analyze, count report, automatic generate test report. Amplify or minify the voltage curve for easy observation.
