60Hz OEM 100kw marine fresh water generator with CCS BV
This genset is powered by Weichai Deutz engine, coupled with Marathon alternator;
Stamford, Siemens and Sanbo alternators are optional;
With Robust foot mounting, Reliable performance and Versatile configurations,
It’s your initial choice for inland power supply.
Any problem, please be free to contact me by skype: justinguo2006, Taizhou, China for instant communication!
Weifang Weichai Deutz Engine Co., Ltd
Genset Feature
Our genset consists of Engine, Alternator, Foot-mounting, Control panel, Radiator, Air filter, Exhaust silencer, Elbow, Expansion joint, Battery, Shock absorber and Operation manual.
Model Number: CCFJ100WDll
Prime Power: 100KW/125KVA
Standby Power: 110KW/138KVA
Rated Voltage: 230V/400V/415V/440V
Rated Current: 180A
Output Type: AC 3 Phase
Speed: 1800rpm
Frequency: 60Hz
Dimension: 2068*798*1340 (for reference)
Weight: 1380kgs (for reference)
Accessories optional: Fuel tank, Canopy, Soundproof enclosure
Diesel Engine Feature
Brand: Deutz
Manufacturer: Weifang Weichai Deutz Co., Ltd.
Model: WP6CD132E201
Rated Power: 120KW
Cyl. and arrangement: 6 inline
Bore/Stroke: 105/130mm
Aspiration: turbocharger
Configuration: water cooled closed, 4-strike, direct injection
Governor: Electronic or Manual
Starting Method: DC24V electric motor or air motor
Fuel Consumption: ≤210 g/kw.h
Accessories optional: Governor of manual or servo, Battery charger, Engine coolant and oil heater, Fuel-water separator
Alternator Feature
Brand: Marathon
Manufacturer: Shanghai Marathon-Gexin Electric Co., Ltd.
Model: MP-H-100-4
Electric capacity: 100KW/125KVA
Configuration: Brushless, self-excited, AVR, 4 poles
Voltage: 230V/400V/415V/440V
Frequency: 60Hz
Power Factor: 0.8(lagging)
Connecting Type: 3 phase, 3 wires
Insulation: Class H
Protection: IP23
Accessories optional: PMG, Alternator space heater, Anti-condensation heater
Control panel Feature
Brand: Smartgen, Harsen
1. Microprocessor control module, with high stability and credibility
2. Monitoring and measuring operational parameters of the generator set
3. Indicating operation status, fault conditions, all parameters and alarms
4. Multiple protections, multiple parameters display like pressure, temp. etc
5. Manual and automatic work mode selectable
6. Language optional of Chinese, English, Russian etc.
7. LED display, touch control
8. Real time clock display and log entries
Function optional: AMF, ATS, Paralleling, Remote control
