500kva diesel generator shangchai marine engine
Shangchai Series Generator sets Main Feature
Power(50Hz):40KW-250KW(50KVA-312.5KVA);
110V,220V,380V,400V,415V,440V,480V,660V,690V are optional;
Electrical start,Spring start and air start are optional;
Engine monitor panel and genset control panel are optional;
Powered by Shangchai engine coupled with Marathon,stamford,Siemens,Landian,Sanbo alternators are optional;
IMO Tier II Certificate;
CCS approved.
Shangchai Dongfeng Engine Technical data
12H Rated Power:440KW
Model:SC33W600CF2
Overload power:484KW
Continous Power:440KW
Oceangoing Rated Output:431KW
Oceangoing Max.Output:474KW
Prime speed:1000RPM
Rated Voltage:400V
Cyl-BorexStroke:6-180x215mm
Alternator Technical data
| Alternator model | TFXW |
| Alternator manufacturer | Kangfu |
| Service Duty | S1 |
| Rated output prime power | 400 KW/500KVA |
| Rated speed | 1000 RPM |
| Rated frequency | 50 Hz |
| Rated voltage | 400 V(Available with customer requirements) |
| Power factor | 0.8 |
| Exc.volt | 23V |
| Exc.curr | 1.7A |
| Insulation grade | H |
| Protection grade | IP23 |
Company Product Pictures
Package:Plywood
Sudong Power Generating Equipment Co.,Ltd is a specialist factory in design and manufacture of generators set such as Marine type,Land Type,Gas Type and Sound-proof generator set,Mobile generator,Disel Pump set.
OEM Manufacturer,high quality,competitive price.
Conforms to ISO9001,CE,CCS,BV,ABS,RINA,DNV,GL etc
More details,welcome to contact us.
Sudong Power will be your reliable partner on Power solutions.
