112.5 Kva Marine Diesel Generator 90KW / CCS BV Certification Authority / HUADONG 90KW Diesel Generator

112.5 Kva Marine Diesel Generator 90KW / CCS BV Certification Authority / HUADONG 90KW Diesel Generator thumbnail-1
112.5 Kva Marine Diesel Generator 90KW / CCS BV Certification Authority / HUADONG 90KW Diesel Generator thumbnail-2
112.5 Kva Marine Diesel Generator 90KW / CCS BV Certification Authority / HUADONG 90KW Diesel Generator thumbnail-3
112.5 Kva Marine Diesel Generator 90KW / CCS BV Certification Authority / HUADONG 90KW Diesel Generator photo-1
112.5 Kva Marine Diesel Generator 90KW / CCS BV Certification Authority / HUADONG 90KW Diesel Generator photo-2
112.5 Kva Marine Diesel Generator 90KW / CCS BV Certification Authority / HUADONG 90KW Diesel Generator photo-3
US$ 4,000 - 29,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
HUADONG
Model Number:
SDM90
Contact Supplier Request Quote Chat Now
Taizhou Sudong Power Generating Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name HUADONG
Model Number SDM90
Output Type AC Three Phase
Speed 1500RMP
Frequency 50HZ
Rated Power 90KW
Rated Voltage 400V
Rated Current 162A

112.5 kva Marine diesel generator 90KW / CCS BV Certification authority / HUADONG 90KW diesel generator

SUDONG POWER is a specialist company in design and manufacture of generator sets.For over 11 years of development ,

SUDONG power has earned the reputation in the market to supply power solutions for various applications with a broad range in power capacities.





Genset general feature:



1.Generator can be used as Main Marine emergency generator

2.CCS,BV approved

3.Cooled by Sea and fresh water heat exchanger

4.Adopt HUADONG Engine

5.Marathon single-shaft alternator standard , Stamford alternator is optional

6.Parallel connection: Two and more normal marine generating sets can transfer loading without stopping ,

and can realize parallel.

7.Standard SAE coupling the engine and alternator

8.With efficiency anti-vibration devices

9.Cold rolled steel one time molded base

10.High reliability , low use and maintenance cost

 112.5 kva Marine diesel generator 90KW / CCS BV Certification authority / HUADONG 90KW diesel generator112.5 kva Marine diesel generator 90KW / CCS BV Certification authority / HUADONG 90KW diesel generator112.5 kva Marine diesel generator 90KW / CCS BV Certification authority / HUADONG 90KW diesel generator

Product information in the data parameters and prices are for reference only, specific product size, weight and price to the actualproductasthestandard



                Diesel engine parameters





1

Brand

 HUADONG

2

Model

6015AZLD

3

Prime power

110KW

5

Governor type

Electronic

6

Configuration


4-cylinder, in-line, four-stroke, turbocharged and intercooled

7

Cooling method

Radiator fan

8

 Bore*Stroke

105*120mm

9



Starting method



 Electric

10

 Dimension

2420*940*1500 mm

11

Weight

2050kg



  Generators Parameters



1

Brand

SANBO

2

Model

SB-HW4(.D)-90

3

Prime power

90KW

4

Configuration

Brushless , self-exciting

5

Prime voltage

400V

6

Frequency

50 HZ

7

Power factor

0.8(lagging)

8

Phase/wire

3 phase 4 wires

9

Isolation

H



 Warranty

Our warranty will be 1000 accumulative hous or 12 month after shipping, whichever comes first.

Certificate & Document

1) Alternator operation and maintenance manual 1PC

2)Engine operation and maintenance manual 1PC

3)Generator Overall drawings of the set 1PC

4)Electrinic system drawing 1PC

5)Bench test 1PC

6)Packing list 1PC

6 Control Panel



 engine section



type of cooling               :Radiator fan

speed adjustment mode : Electronic Speed governing

control cabine           :cntrol cabinet



Generator part  Brushless copper, self-excitation, AVR







steel seat

shock pad

accessories section: diesel engine,electric generator,

Random standard tools and spare parts manufacturer

 technical documents:Diesel engine and generator manual,CCS,ZC or ZY Substituting certificate



 Increase for part



Fire star muffler

Start the battery or air compressor

Remote control instrument

three filters ,sea water pump,Vulnerability consumable such as leather belt

stand alone type  or   Base oil tank

low noise  or  rain cover   anti-condansation heater





 112.5 kva Marine diesel generator 90KW / CCS BV Certification authority / HUADONG 90KW diesel generator

112.5 kva Marine diesel generator 90KW / CCS BV Certification authority / HUADONG 90KW diesel generator

  112.5 kva Marine diesel generator 90KW / CCS BV Certification authority / HUADONG 90KW diesel generator112.5 kva Marine diesel generator 90KW / CCS BV Certification authority / HUADONG 90KW diesel generator
