SUPER200 Multi-function AC/DC TIG/MMA/CUT Welding Tools

SUPER200 Multi-function AC/DC TIG/MMA/CUT Welding Tools thumbnail-1
SUPER200 Multi-function AC/DC TIG/MMA/CUT Welding Tools photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
RONGYI
Contact Supplier Request Quote Chat Now
Shanghai Rongyi Welding Corporation
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name RONGYI
Model Number SUPER200
Arc Current 200A
Pulse Frequency 5~12HZ
Pilot Arc Current 10A
Rated Duty Cycle 60%
Motor Type DC Motor
Dimensions 520*330*375
Usage cut tig mma
Voltage AC 220±10% V / 50~60 Hz
Power(W) 4.6 kVA
Certification CCC, CE, ISO9001
Warranty 1 YEAR

Specifications

MOSFET, AC/DC and pulse output, high duty cycle,high frequency,easy for maintenance for muti-function welding machine SUPER-200

The parameters of  Multi-function AC/DC TIG/MMA/CUT Welding tools SUPER200 is as following: welding machine



          Model

Spec.

SUPER200

Power supply voltage

AC 220±10% V / 50~60 Hz

Power supply capacity

4.6 kVA

Rated input current

20.7A

Output current range(TIG)

10-200 A

Output current range (MMA)

10-170 A

Output current range (CUT)

25-50 A

No-load voltage (TIG)

56 V

No-load voltage (MMA)

56 V

No-load voltage (CUT)

220 V

Pre-flow time

1-3 S

Post-flow time

2-10 S

Attenuation time

0-5 S

Efficiency

85%

Air pressure

0.4 MPa

Cutting thickness

1-10 mm

Insulation grade

B

Cosφ (η)

0.95

Protection

IP 21 S

Net Weight

23.5 kg

Dimensions (mm)

520*330*375



SUPER200 Multi-function AC/DC TIG/MMA/CUT Welding toolsSUPER200 Multi-function AC/DC TIG/MMA/CUT Welding tools

  FEATURES of Multi-function AC/DC TIG/MMA/CUT Welding tools SUPER-200:

1.Reactive power correction, MOSFET, AC/DC or pulse output , soft switch, inverter with 100 kHz high frequency;

2.Compact structure, stable welding current, steady and intensive arc, reliable and durable, easy for maintenance;

3.Excellent control performance, multiple functions of TIG, MMA and CUT;

4.The model with P means function of pulse with 9 regulator knobs, and the model without P has only 5 regulator knobs;

5.Thermostatic protection, over-voltage protection, over-current protection, under-voltage protection, pedal control interface for safe operation;

6.Complete accessories: welding torch, cutting torch, welding holder, earth clamp, compressed air regulator, etc.
