Low cost hobby best plasma cutting machine price sell to Thailand

Machine Features

For thin plate cutting 0.3mm to 50mm mild steel plate cutting.

Very high cutting speed up to 36m/min to ensure the thin plate not be burnt.

Small kerf,precise cutting ,not cutting residue avoiding complementary reworking

Compatible with most common cutting software like Fastcam,Arc cut, ArtCAM.

Compact size and no need installation.

Benifit :

The machine mainly consists of work table, beam, trolley, guide rail and CNC system. Beam and trolley adopts steel structure. Longitudinal direction

adopts belt pulley hard synchro structure, transversal and longitudinal guide rails adopt Φ25mm ball bearing steel. CNC system adopts

10" Honeybee CNC system, support all kinds of plasma sources.

1. Longitudinal driving adopts beltpulley hard synchrostructure. A sychro shaft cross the beam,which realized electrical part and mechanical part synchronized movement.

2.Adopts high torque (15NM) AC servo motor,equal to 4sets of 750W motors. Speed adjusting range 0--36 m/min.(common machine speedjust max12m/min.

High inertiamotor driving,machine runningmore stable, better cutting quality!

3.Adopts synchro belt to buff and absorb shock,getgood cutting quality.

 Low cost hobby best plasma cutting machine price sell to Thailand

Machine parameter

Machine photos

Cutting works:

Plasma power cutting thickness:

1.Plasma domestic Huayuan Power:

-63A cutting thickness: 0-6mm mild steel

-100A cutting thickness: 0-10mm mild steel

-160A cutting thickness: 10-15mm mild steel

-200A cutting thickness:0-35mm mild steel

2.USA Hypertherm power supply :

-65A cutting thickness: 0-12mm mild steel

-85A cutting thickness: 0-16mm mild steel

-125A cutting thickness: 0-25mm mild steel

-400A cutting thickness:0-80mm mild steel

CNC plasma cutting machine  applications:
