Low Cost Plastic Tube Type Water Rotameter
Specifications
low cost plastic tube type water rotameter1. high precision
2. wide measure range
3. PTFE leader for sea water
low cost plastic tube type water flow meter (rotameter)
Technical Parameters of LZS Series
|
Diameter (Dg)mm |
Model |
Measure Range |
Accuracy |
Media State |
||
Long Tube Type |
Short Tube Type |
Temperature |
Pressure |
|||
15 |
LZS-15 |
10-100 l/h 16-160 l/h 25-250 l/h 40-400 l/h 60-600 l/h
|
5-50 l/h 10-100 l/h 16-160 l/h 25-250 l/h 40-400 l/h 50-500 l/h 60-600 l/h 100-1000 l/h |
±4% |
0-60 |
≤0.6 |
25 |
LZS-25 |
100-1000 l/h 160-1600 l/h 250-2500 l/h |
100-1000 l/h 160-1600 l/h 4-40 l/min 250-2500 l/h |
|||
32 |
LZS-32 |
|
0.4-4 m3/h 0.6-6 m3/h |
|||
50 |
LZS-50 |
0.4-4 m3/h 0.6-6 m3/h 1-10 m3/h 1.6-16 m3/h |
1-10 m3/h 1.6-16 m3/h |
|||
65 |
LZS-65 |
|
2.5-16 m3/h 5-25 m3/h 8-40 m3/h 12-60 m3/h |
|||
100 |
LZS-100 |
|
14-90 m3/h 18-120 m3/h |
|||
125 |
LZS-125 |
|
25-150 m3/h 25-180 m3/h |
|||
150 |
LZS-150 |
|
14-90 m3/h 18-120 m3/h 25-150 m3/h 25-180 m3/h 25-200 m3/h |
|||
The drawing and installation size of LZS-Durable Plastic Tube Type Rotameter Flow Meter
Model |
Size (mm) |
Suit Pipe (Dg)mm |
|||||
Long Tube Type |
Short Tube Type |
||||||
L |
D1 |
D2 |
L |
D1 |
D2 |
1520 |
|
LZS-15 |
280 |
20 |
45 |
202 |
20 |
45 |
|
LZS-25 |
380 |
32 |
68 |
226 |
32 |
60 |
2532 |
LZS-32 |
|
|
|
288 |
40 |
74 |
3240 |
LZS-50 |
430 |
63 |
98 |
341 |
63 |
98 |
5063 |
LZS-65 |
|
|
|
430 |
75 |
22 |
6575 |
LZS-100 |
|
|
|
550 |
17 |
175 |
100 |
LZS-125 |
|
|
|
550 |
17 |
175 |
125 |
LZS-150 |
|
|
|
560 |
21 |
240 |
150 |
LZS-C Long Tube Type ,LZS-D Short Tube Type
