Specifications
1, Microcomputer touch-type control, easy to operate.2.Imported pump with large pressure and flow rate ensures uniform tempera
KTC-series Mould Temperature Controller
Features:
1, Microcomputer touch-type control, easy to operate.
2, PID controlled touch-type memory for automatic computation,with temperature control at ±1°C and 35% energy saved.
3, Imported pump with large pressure and flow rate ensures uniform temperature on mould.
4,Brand-new design ,elegant outlook, compact size and convenient maintenance.
4, Completely stainless steel made bladder and high-Pressure blast proof piping.
Safety protection system:
Main power over-current breaker
Motor reversal protection and indication
Low oil protection and indication
Overheating pump overload protection and indication
Abnormality alarm buzzer and indication
Phase failure protection
Specifications:
Model |
Max .temp. (°C) |
Heating capacity (kw) |
Diathermanous Media |
Power (HP) |
Pressure (kg/cm) |
Flow (L/min) |
Oil Tank Volume(L) |
Pipe Dia |
Dimensions (cm) |
Weight (kg) |
KTC-1 |
120 |
6 |
Oil |
1 |
4.0 |
60 |
8 |
2*1/2” |
65*28*70 |
60 |
KTC-2 |
95 |
6 |
Water |
1 |
4.0 |
60 |
8 |
2*1/2” |
65*28*70 |
60 |
KTC-3 |
150 |
9 |
Oil |
1 |
4.0 |
60 |
8 |
2*1/2” |
65*28*70 |
60 |
KTC-2C |
200 |
9 |
Oil |
1 |
5.0 |
60 |
8 |
2*1/2” |
65*28*70 |
70 |
