Help CenterFrame Straightener
Related Products
Specifications
Platform length: 3400mmPlatform width: 850mm
Platform height: 120-1200mm
Pulling power of tower: 10tons
Pulling tower heigh
Easy operation, simple and practical, easy for vehicle upload and download, suit for all of the cars
W-1000 is a generation auto collision repair system developed by WANT Company, embodying years of experience in automobile collision and repair according to repairing conditions in the country. Our product is designed well and priced reasonably, which thoroughly reflects on the auto body repair idea of exact, quick and practical and accord with the repair habit of repair technician and repair request of auto body straightening.
1. High-grade configuration, reasonable price and best performance.
2. The sidewise lift platform facilitates any accident vehicle up and down,
3. The hydraulic twin-pulling tower cans flexible work at an angle from 0 degree to 360 degree on the ring platform which is designed with patent of sliding track.
4. The high-quality steels are forged to streamlined clamp. The clamps have higher strength, greater load and longer service life.
5. The furnished W-100 measuring tool developed by WANT Company makes the complex measure work more quick, convenient and effective.
6. The auto body data is supplied by Mitche II Company and major automobile companies in the country.
7. The imported assembly hydraulic system is powerful, reliable and of a long service life.
8. The perfect service system gives you the best reliable guarantee.
SPECIFICATIONS:
Platform length: 5200mm
Platform width: 2100mm
Platform height: 500mm
Hydraulic pressure: 70Mpa (1000psi)
Post Max.tension: 95KN
Post working range: 360degree
Pneumatic pressure range: 0.8Mpa
Max.lifting weight: 3000kg
Total weight: 2200kg
N.W:2200KG
G.W:2300KG
Cubic measure: 5.5CBM/SET
Package number: 2 packages
Exterior dimension: platform: 5300mmx2200mmx200mm
Salver: 2300mmx1300mmx1000mm
