Liming High Utilize Ratio and Low Consumption of Spray Coating Machine

Liming High Utilize Ratio and Low Consumption of Spray Coating Machine thumbnail-1
Liming High Utilize Ratio and Low Consumption of Spray Coating Machine photo-1
US$ 1 - 99,999,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Roller Crusher
Application:
Mining, metallurgy, construction, highway, railroad, and water conserv
Contact Supplier Request Quote Chat Now
Henan Liming Heavy Industry Science & Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai or Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Roller Crusher
Application Mining, metallurgy, construction, highway, railroad, and water conserv
Motor Type AC Motor
Power(W) 15kw, 30kw, 30kw, 55kw, 75kw, 110kw, 130kw, 130kw, 200kw
Capacity(t/h) 5-20tph, 15-50tph, 15-60tph, 50-100tph, 60-130tph, 110-250tph, 160-380
Place of Origin Henan, China
Brand Name LIMING
Model Number PE250x400, PE250x1000, PE400x600, PE500x750, PE600x900, PE750x1060, PE
Dimension(L*W*H) 1150x1275x1240mm, 2790x2670x1380mm, 1700x1732x1653mm, 2035x1921x2000mm
Weight 2.8t, 6.5t, 6.5t, 10.3t, 15.5t, 26.7t, 51t, 56t, 88t
Certification ISO9001:2000
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

If you would like to receive the price and detailed specifications of our copper crusher, type d-mk-1 3.2 tonnage, please Leave Us a message Below!!





Liming High utilize ratio and low consumption of spray coating machine







Features of copper crusher, type d-mk-1 3.2 tonnage

1. High ratio of crushing,

2. Even final size,

3. Simple structure,

4. Reliable working condition,

5. Easy maintenance, 6. Low operating cost.





 Liming High utilize ratio and low consumption of spray coating machine

Working Principle of copper crusher, type d-mk-1 3.2 tonnage

The motor transmits power through belt, drives the moving jaw to do periodic motion towards the fixed jaw by the eccentric shaft. The angle between toggle plate and moving jaw plate increases when moving jaw moves . So the moving jaw moves towards the fixed jaw. The stuff will be crushed in this process. The angle between toggle plate and moving jaw decreases when moving jaw moves down, the moving jaw moves leaves fixed jaw by pulling rod and spring, the final crushed stuff will be discharged from the outlet.







Specifications of copper crusher, type d-mk-1 3.2 tonnage

Model Max. Feeding Size (mm) Adjustable Discharge opening (mm) Capacity (t/h) Motor Power (kW) Overall Dimensions (mm) Weight (t)
PE250×400 200 20-60 5-20 15 1150×1275×1240 2.8
PE250x1000 210 15-50 15-50 30 2790x2670x1380 6.5
PE400×600 350 40-100 15-60 30 1700×1732×1653 6.5
PE500×750 425 50-100 50-100 55 2035×1921×2000 10.3
PE600×900 500 65-160 60-130 75 2290×2206×2370 15.5
PE750×1060 630 80-140 110-250 110 2620×2302×3110 26.7
PE900×1200 750 100-200 160-380 130 3789×2826×3025 51
PE1000×1200 850 200-300 315-550 130 3889×2826×3025 56
PE1200×1500 1020 150-350 400-800 200 4200×3750×3820 88

Note:Any change of technical data shall not be advised additionally.

Certificate



We have got the certificate of European Union CE certification, ISO international quality system certification, and SZUTEST certification.



Liming High utilize ratio and low consumption of spray coating machine

About Liming



Henan LIMING Heavy Industry Science and Technology Co. LTD which mainly manufacture large and medium-sized crushing and grinding equipments was founded in 1987. It is a modern joint-stock corporation with research, manufacturing and sales together.

Liming High utilize ratio and low consumption of spray coating machine



The company headquarters is located in Zhengzhou National Hi-Tech Industrial Development Zone, where is mixed with tradition and innovation, with an area of 80,000 square meters. The machinery and equipment Industrial Park which is located in Shangjie covers an area of 67,000 square meters.





The products of Liming Heavy Industry have the highly quality and advanced technology. The General Research Institute focuses on research and development of advanced technology and customer-oriented products as well as building up core competitiveness to makes Liming Heavy Industry being the best in the industry. What’s more, LIMING got ISO international quality system certification, European Union CE certification and Russian GOST certification. The company has strong research and development strength and innovation.



As a high-end crushing, grinding and assembling company, LIMING values the technology exchange and cooperation with overseas countries. It wins the huge foreign market with mature product and perfect service system. Liming products are exported to more than 100 countries and districts all over the world such as Russia, Central Asia, Middle East, Africa, Southeast Asia, Australia, European Union, North America, South America, etc.





Over the past 26 years, our company adheres to modern scientific management system, precision manufacturing, pioneering and innovation. Now LIMING has become the leader in domestic and oversea machinery manufacturing industry.
