Help CenterEPDM Single Ball Flexible Rubber Joint for Pipe Connection
Related Products
-
EPDM Ruber Single Ball Rubber Joint for Pipe ConnectionUS$ 3 - 400MOQ: 1 Piece -
Twin /Double Sphere Flexible Rubber Joint With FlangeUS$ 3 - 400MOQ: 1 Piece
-
Nice Compensation Performance Flexible Rubber JointUS$ 3 - 400MOQ: 1 Piece
-
Good Shock Absorption Single Ball Flexible Rubber Joint With FlangesUS$ 3 - 400MOQ: 1 Piece
-
EPDM Single Ball Rubber Joint From Henan ManufactureUS$ 3 - 400MOQ: 1 Piece
Specifications
Flexible Rubber Joint for pipe connectionGood compensation
Good shock absorption
Nice noise reduction effect
MEIQI RFJD Single sphere flexible rubber joint
Flexible rubber joint is also know as flexible rubber expansion joint ,rubber pipe soft joint ,high-pressure rubber joint ,pipe shock absorber,compensator etc.
Application:
Water supply system ; Heating ventilation air condition ; Shipbuilding ; Fire pretection ; Compressor ; Pharmacy ;
Fan and other piping connection etc.
Product structure and materials :
1. Flange : Forging soft steel
2. Inside lining layer : Aging resistance polar rubber
3. Reinforcing layer : Nylon fabric
4. Middle lining layer : Nitrile rubber
5. Outside lining layer: Aging resistance polar rubber
6. Bead ring : High strength coppered steel wire
Main specification:
1. Diameter : 32-2800 mm
2. Applicable flange :2.5-0.6 Mpa (25-6 kgf/cm2)
3. Working pressure :2.5 -0.25 mm (25- 2.5 kgf/cm2)
4. Bursting pressure :7.5-0.75 MPa (75-7.5 kgf/cm2)
5. Vaccum degree :100- 19.9KPa (750-150 mmHg)
Main parameter:
| Nominal Diameter |
Length | Flange thickness |
Bolt Qty |
Diameter of bolt hole |
Central diameter of bolt hole |
Axial displacement | Horizontal displacement |
Deflection angular |
|
| mm | mm | b mm | n | d mm | D mm | extension | compression | mm | (α1+α2)° |
| 32 | 95 | 14 | 4 | 18 | 100 | 6 kgf/cm2 |
91kgf/cm |
9 | 15° |
| 40 | 95 | 16 | 4 | 18 | 110 | 6 | 10 | 9 | 15° |
| 50 | 105 | 16 | 4 | 18 | 125 | 7 | 11 | 10 | 15° |
| 65 | 115 | 18 | 4 | 18 | 145 | 7 | 12 | 11 | 15° |
| 80 | 135 | 18 | 8 | 18 | 160 | 8 | 13 | 12 | 15° |
| 100 | 150 | 20 | 8 | 18 | 180 | 10 | 13 | 13 | 15° |
| 125 | 165 | 22 | 8 | 18 | 210 | 12 | 14 | 13 | 15° |
| 150 | 180 | 22 | 8 | 22 | 240 | 12 | 22 | 14 | 15° |
| 200 | 200 | 22 | 8 | 22 | 295 | 16 | 22 | 22 | 15° |
MORE OTHER SIZE for sale !!!
Products picture :
Packaging :
Carton or according to customer's requirement.
Shipping :
Within 1week after receivie customer'official order.
1. Would based on customer's requests, supply the most suitable type.
2. Always do best effort for satisfing customer's requests.
3. Fastest Delivery. Usually can shipping goods within 15 days after get the official order.
4. Service customer even customer had got our goods, always reply customer's requirements at earliest!
5. Price most competitive! Insure the confirmed QUALITY!!!
Any question or requirements, welcome contact us at any time~~ :)
MEIQI Industry & Trade Co.,Ltd. Is a professional manufacturer and exporter company for kinds of water treatment materials ,water supply products ,chemical materials and other raw materials for industry.
Our flexible rubber joint sales in China mainland more than 10years.Now we are committed to export our product all over the world . Any question about our products please contact us.
