Quick Details of Electric Propeller Centrifugal Blade Dryer | |
Brand Name |
Lotrot |
Model Number |
QJ3 |
Dimension(L*W*H) |
2972*736*762 |
General Description of Electric Propeller Centrifugal Blade Dryer | |
Applicable for drying or cooling of paste, particle, powder and slurry state of material, perform the process of drying, cooling, heating, sterilizing, reacting and combustion under low temperature. The special stirring and heating transferring blade, makes high heat transferring efficiency, and provide self-cleaning function. The special chock shaped stirring and heat transferring blade has high heating efficiency and self-cleaning function of the heating transferring surface. | |
Work Principle of Electric Propeller Centrifugal Blade Dryer | |
Hollow chock shaped blades are concentrated on the hollow shaft. Heat media flow through the blade from the hollow shaft. The heat transferring area in the effective volume is very high. The temperature range of heating media is -40 to 320 . It might be steam, or liquid state, such as steam, thermal oil etc. Indirect heating, there's no heat carried out by air. All heat is utilized for to drying the material except the lost of heat insulation layers. The surface of chock shaped blade has self-cleaning function. The relative movements of the product particles and the chocked shaped surface might clean the material attached to the chock shaped surface, so to keep the cleanliness of heat transferring surface during working. The shell of hollow blade dryer is shape. 2 or 4 pieces of hollow stirring shaft are usually equipped in the shell. To avoid any leakage of material, there're sealed terminal cover and top cover with the shell. The heat transferring media flow through the rotation connector, jacket's shell and hollow stirring shaft. To ensure best transferring effect, the hollow stirring shaft adopts different interior structure in accordance with different heating media. | |
Features of Electric Propeller Centrifugal Blade Dryer | |
1. The heat consumption of blade is low: No heat carried out by the air because of indirect heating; there's no heat insulation layer with the exterior wall of the dryer. It consumes 1.2 kg of steam to evaporate 1kg of water for to drying slurry state of material. | |
Specification of Electric Propeller Centrifugal Blade Dryer | |
| |
Application of Electric Propeller Centrifugal Blade Dryer | |
The blade dryer is successfully applied in foodstuff, chemical, petrochemical, dyestuff, and industrial mud etc. The heating transferring, cooling and stirring characters enable it to perform the following unit operation: combustion (low temperature), cooling, drying (recovery of solvent), heating (melting), reacting and sterilizing. The stirring blade is heat transferring surface too, so to increase heat transferring area of unit effective volume is increased, and decrease processing time. The chock shaped heat transferring surface has self-cleaning function. Compressing and swell-stirring functions make the material mixed uniformly. The material perform the movement of "piston flow" along the shaft. The difference of the temperature, humidity and mixing effect are very small in the different axial area. The blade dryer is capable to perform combustion under low temperature if we adopt thermal oil as heating media, so to save power and the processing equipment for tail air, and save operation cost. Drying is the main function of this machine. Drying without hot air makes the process of solvent recovery, energy consumption, control of environment ideal, easy to teat. It's specially applicable for recovery of solvent and heat sensitive material that is easy to be combusted or oxidized. It has been widely used in fine chemical, petrochemical, and dyestuff industries. The uniformity of temperature, humidity and mixing effect in axial areas make the equipment capable for heating and melting, or reaction of solid material. It's successfully applied in mixed fertilizer and character transformed starch industries. The blade dryer is also capable for sterilizing food and starch. The big heating area in unit effective area, dry the material to sterilizing temperature very fast, so to avoid quality change caused by long time heating. | |
Company Information | |
|
Jiangyin Lotrot Commerce Co., LTD is the subsidiary company of Jiangyin Hengtai Drying Equipment Co., LTD,which is specialized in producing drying equipment.
| |
Factory Advantage | |
Manufacturer | |
Project Case | |
| |
Our Customer | |
| | |
Packing and Shipping of Electric Propeller Centrifugal Blade Dryer | |
Packaging Details:wooden case | |
LOROT Support | |
|
Besides domestic market,our products has been exported to Russia,France,Japan,Turkey,Uzbekistan,etc. We insist on "the quality of products is our life" all the time,and guarantee the quality of goods strictly and offer the best service to our customers. Pre-sale Service: 1,Selection of Equipment Model; 2,According to customer's requirement,providing schematic design and structure chart; 3,FreeTrial of customer's sample ,and providing installation drawing and structure chart after satisfying with the result of sample testing; 4,Designing and Manufacturing the equipment for customer based on customer's requirement. After-sale Service: 1,1 year warranty ; 2,Life-long service after sale; 3,Staff Training 4,Technical Assistance of our technical engineer. | |
