Help CenterZYSZ High Quality Hot Peanutlinear Separator Machine in China
Related Products
-
ZYC High Quality Ultrasonic Rotary Screen Machine With CE & ISOUS$ 1,000 - 10,000MOQ: 1 Set -
ZYD High Quality and Efficiency Rotary Vibrating Screen Filter ManufacturerUS$ 1,000 - 5,000MOQ: 1 Set
-
Professional ZYC Ultrasonic Sieving Machine for Sale With CE & ISOUS$ 1,000 - 100,000MOQ: 1 Set
-
Professional ZYC Ultrasonic Sieving and Filtering ManufacturerUS$ 1,000 - 100,000MOQ: 1 Set
-
Admirable ZYC Ultrasonic Powder Sieving MachineUS$ 1,000 - 100,000MOQ: 1 Set
specialized in sieving,conveying,crushing and feeding equipment.
High quality product and service,hard-woking and cooperative spirits accelerate the growth
of Zhenying company.
With ISO9001:2008,CE Certificate,AAA credit company and many government credits,our
products are your best choice.
Zhenying means flying eagle in Chinese,hope we can fly far away in the sky of world machinery.
This series machines use excellent vibrant motor as power source, so that the materials can be
thrown up on the sieve and forward to make a straight movement. It can be equipped with
single or multi-screen to achieve the grading, removing impurity, removing dust, testing,
washing selecting, dehydration etc.
Detail
Mesh
Spring ring
Motor
Working principle
Technical Parameter
Model |
Screen Specification (mm) |
Layer |
Mesh Size (mm) |
Particle Size (mm) |
Vibrating Frequency (r/min) |
Double Amplitude (mm) |
Power (KW) |
Vibrating Direction Angle (°) |
|
ZYSZ525 |
500×2500 |
1--6 |
0.074-10 |
0.06-15 |
960, 1450 |
4--8 |
2×0.4, 2×0.75 |
45-60 |
|
ZYSZ1020 |
1000×2000 |
1--6 |
0.074-10 |
0.07-20 |
960 |
4--8 |
2×0.75, 2×1.5 |
45-60 |
|
ZYSZ1025 |
1000×2500 |
1--6 |
0.074-10 |
0.07-15 |
9,601,450 |
5--8 |
2×0.4, 2×0.75 |
45-60 |
|
ZYSZ830 |
800×3000 |
1--6 |
0.074-10 |
0.1-20 |
960 |
6--8 |
2×0.75, 2×1.5 |
45-60 |
|
ZYSZ1030 |
1000×3000 |
1--6 |
0.074-10 |
0.1-20 |
960 |
6--8 |
2×0.75, 2×1.5 |
45-60 |
|
ZYSZ1224 |
1200×2400 |
1--3 |
0.074-10 |
0.1-23 |
960 |
6--8 |
2×0.75, 2×1.5 |
45-60 |
|
ZYSZ1230 |
1200×3000 |
1--3 |
0.074-10 |
0.1-23 |
960 |
6--8 |
2×1.5 |
45-60 |
Application
ZYSZ Factory Customized high capacity cement linear vibration screen
It is widely used in grinding materials, chemical, construction, chemicals, pharmacy, metallurgy,
ceramics, fertilizers, coal industry to screening and grading the granular and powder bulk materials.
Feature
1. High sieving efficiency, high utilization ratio of screen, with bouncing balls set under the screen
which eliminates mesh blockage, increasing precision of sieving.
2. Continuous working.
3. Fully enclosed structure avoids dust overflow, reaching the request of sanitation.
4. Rubber springs may be used on customers’ requests, which would considerably reduce running
noise, improving labors’ working environment.
5. Simple and rational tensioning mode of screen, easy to replace.
6. The screen frame may be replaced as per different mesh numbers, saving running cost.
Our advantage
1.Our machine idle running for 48 hours before shipment.
2. 13 months guarantee for the machine,except wearing parts.
3. We have export experience more than 5 years, and passed the CE and ISO Certificate.
4. We have a professional team of engineers, support engineer on site installation and maintenance.
5. Provide the professional video and a warm, efficient, professional service.
6.The order service: during the production, all tracked by pictures.
Special needs can tell us (like "made in China" sprayed on the case).
1.Installation,Debugging.
Provide installation files, technical data and related soft copies or videos
etc to ensure customer could install and debug by themselves.
2.warranty
The provider guarantee the vibrating screen could meet production technical
standard and performancerequirements indicated in the contract, 24 months
for the machine after delivery ,12 months for the motor after delivery.
3.Technical Support
Our company will make occasional call to find problems and solve them in
time.Provide technical support timely.
4.Response Time(24 hours)
Contact us through Telephone or Email, we will respond within 24 hours.
Certification
Please provide the following information to help us recommend a right machine for you:
1.material to be processed?
2.using purposes:to grade or to remove dusts?
3.granule size of material? Or mesh number?
4.moisture content if any?
5.granule size proportion if possible to get?
6.capacity(tons or kg or litter per hour or day)?
local power supply(voltage and frequency)?
