Help CenterGold Magnetic Separator Machine
Related Products
Specifications
1.Report:CE, SGS, ISO2.Material Certificate: RoHs
3.OEM
4.Consist of rows of round magnetic tubes (installed in drawer)
Hi! This is Avy,what can i do for you?
If you have any question,don’t hesitate to contact me!
When the material flows through the rotating permanent magnet Separators, the ferromagnetic
material in it is to be adsorbed on the magnet bar in internal permanent magnet, finally, the
separation of the ferromagnetic material and material is finished.
The dry magnetic separator can be used for separating iron from the materials with high apparent
viscosity and poor fluidity.
The connections can be made to square chute or round pipeline flange to meet your installational
requirement.
Performance and Characteristics :
(1).Quick-detachable and easy clearance.
(2).The peak of magnetic field intensity reaches 12,000GS.
(3).The quantity of axial magnet can be increased or reduced according to the properties of
materials.
(4).Covered with stainless steel shell,welded with excellent technique,high gradient magnetic
separator is featured by strong tension, big pulling and good separation precision.Applicable to all
kinds of bulk materials.
(5).It can be suitable for the materials with viscosity and poor fluidity strong force because of
deagglomeration, and especially for efficient removing iron existing in superfine powder.
(6).The temperature of standard products is > 80, the separators can be used up to 200¡æ by our
high-temperature types.
Part No |
¢A |
B |
C |
H |
KW |
No Rods |
Weight(Kg) |
ZYMRG150 |
150 |
205 |
208 |
450 |
0.25 |
7 |
30 |
ZYMRG200 |
200 |
255 |
258 |
500 |
0.25 |
9 |
38 |
ZYMRG250 |
250 |
305 |
308 |
550 |
0.25 |
11 |
50 |
ZYMRG300 |
300 |
355 |
358 |
600 |
0.37 |
13 |
62 |
ZYMRG350 |
350 |
405 |
408 |
650 |
0.37 |
15 |
78 |
ZYMRG2020 |
205 |
208 |
270 |
0.25 |
7 |
28 |
|
ZYMRG2525 |
255 |
258 |
320 |
0.25 |
9 |
35 |
|
ZYMRG3030 |
305 |
308 |
370 |
0.25 |
11 |
47 |
|
ZYMRG3535 |
355 |
358 |
420 |
0.37 |
13 |
28 |
|
ZYMRG4040 |
405 |
408 |
470 |
0.37 |
15 |
70 |
Application Fields:
Suitable for removing iron from powdery materials in the fields of cement, building materials,
chemicals, coal, food, plastics, refractory, and in conjunction with the various storage bin, dust
catcher and other equipment.
