Home > Products > New Products > High performance ATMEL AT91SAM9263 CPU ARM discovery board
High performance ATMEL AT91SAM9263 CPU ARM discovery board
- 100000 Piece / Pieces per Month
- Shanghai/Ningbo
- T/T L/C D/P D/A Credit Card PayPal
Product Details
D/C: | QY-9263K | Package: | BGA | Model Number: | QY-9263K |
Brand Name: | QY | Place of Origin: | Zhejiang, China |
Product Description
High performance ATMEL AT91SAM9263 CPU ARM discovery board
High performance ATMEL AT91SAM9263 CPU ARM discovery board Specifications
Core Module is designed by 6-floor PCB; the volume is only card size(80*53mm), together with CPU, SDRAM, NandFlash, DataFLash; using 3.3V dc power supply, low power consumption; B to B(2*100)connectors lead various commonly used interfaces; suitable for the customers those who not plan to design CPU board by themselves next devolop.
High performance ATMEL AT91SAM9263 CPU ARM discovery board
CPU Processor
• ATMEL AT91SAM9263, ARM926EJ-S Core
• 200MHz
SDRAM Memory
• 64MB SDRAM, 2-piece 4Banks x 4Mbitsx16bits SDRAM
FLASH Storage
• On-board 512K DataFlash (DB45041D)
• On-board 128M*8bits NandFlash (K9F1G08U0B)
• Could change large capacity or industrial chip according to customer's request
Interfaces
• 2*100 pin 0.8mm spacing B to B (the connectors are 350°C high temperature-tested and seismic-tested)
Specification & Size
• Using six floors of PCB high precision process, and has the best electrical properties and anti-jamming performance
• 80x 53 x 1.5mm
Working Parameters
• Working temperature: -20°C~ 70°C (batch user could customize -40°C~ 85°C)
• Humidity Range: 5%~ 95%, Non-Condensing
Low Power Consumption
• 3.3V Dc power supply, low power consumption, <1W
Support OS
• Linux2.6.30 + QT QT2.3 default/ QT4 has supported
• Windows 5.0, WindowsCE 6.0
High performance ATMEL AT91SAM9263 CPU ARM discovery board Software & Technical Support
Cross-compiler | arm-2007q1-10-arm-none-linux-gnueabi-i686-pc-linux-gnu.tar.bz2 | arm-linux-gcc 4.2 |
U-boot | Version: U-boot 1.3.4 | Provided with bootstrap, U-boot source code |
Support writing into DataFlash or NandFlash start | ||
Support SAM-BA software with USB writing and TFTP network update | ||
Linux Kernel | Version: 2.6.30 | |
RTC driver, save and restore system time after power off | Provided with test program and source code | |
CAN driver | Provided with test program and source code | |
Ethernet driver | Provided with test program and source code | |
Audio driver | Provided with test program and source code | |
LCD driver, supporting 320*240, 640*480, 800*600,1024*768 resolution | Provided special LCD with debug service | |
Touch screen driver, supporting 4-wire resistive screen | Provided with test program and source code | |
Serial driver | Provided with test program and source code | |
Buzzer driver | Provided with test program and source code | |
GPIO driver | Provided with test program and source code | |
8*8 matrix keypad driver | Provided with test program and source code | |
USB driver | Support various USB external devices, provided with debug service | |
IDE driver | Support various IDE equipment | |
CF card driver | Support large capacity CF card | |
SD card driver | Support large capacity SD card storage | |
File System | Jffs2 file system | Provided with source code |
PC Development Environment | Provided ubuntu 10.10 development environment and VM7.1.4 virtual machine | Provided with development environment build manual |
High performance ATMEL AT91SAM9263 CPU ARM discovery board
Bootloader | support writing into DataFlash or NandFlash start | Optional |
support user-defined boot logo | Up to 1024*768 resolution 24 bmp image | |
BSP Source Code | ||
BSP Open Source
| RTC diver, save and restore system time after power off | Provided with test program and source code |
Registry saving, support saving registry information when electricity adjusted | Convenient for user to debug | |
LCD driver, support 320*240, 640*480, 800*600, 1024*768 resolution | Provided special LCD with debug service | |
Touch screen driver, support 4-wire resistive screen | Provided with test program and source code | |
SD card driver, support 2-wire SD card | Biggest support 4G | |
Audio driver, support audio input/output and MIC input | Provided with test program and source code | |
Nic driver, 10/100M self-adaptive, can be expanded gigabit nic | Provided with test program and source code | |
CF card driver | Support large capacity CF card | |
IDE driver | Support various IDE equipment | |
Serial driver | Provided with 232, 485 test program and source code | |
support 8*8 matrix keypad, also can used as GPIO | Provided with test program and source code | |
USB driver, support mouse, keypad, U disk, printer, WiFi, bluetooth, camera, barcode scanning, etc. | According to user's selection, debug driver | |
PC Development Environment
| Wince6.0: Provided with supporting VS.NET 2005 development tools, Wince 6.0 plug-in Wince5.0: Provided with supporting EVC development tools, Wince 5.0 plug-in | Convenient for user to next develop |
Item | QY-9263K | ||
---|---|---|---|
Standard accessories | (1)12V/2A power supply (2)1-wire cross serial line (3) CD of DVD development (4)4-wire RS232 serial line (5) USB cable (6)exquisite packing box | ||
CD resources | Linux | Compilers | Cross-compiler arm-linux-gcc |
Tool software | Supporting terminal, writing, download tools | ||
Device manual | Main components' datasheet of back plane | ||
User manual | About all development and use | ||
Image file | Bootstarp, u-boot, kernal, image file of file system | ||
Test source code | Test routines and source codes of all interfaces | ||
System source code | Including bootstrap, u-boot, kernel, file system and QT source code | ||
Schematic | Back plane's schematic in PDF format | ||
Packaging library | Component packaging library of evaluation board | ||
Windows CE | Tool software | Supporting terminal, writing, download tools, sync software | |
Device manual | Main components' datasheet of back plane | ||
User manual | About all development and use | ||
Image file | Firstboot, Eboot, NK image file | ||
Test source code | Test routines and source codes of all interfaces | ||
BSP package | Related BSP board-level supporting package | ||
SDK | Related SDK | ||
Schematic | Back plane's schematic in PDF format | ||
Packaging library | Component packaging library of evaluation board | ||
LCDoptions
| 4.3' LCD module + 4-wire resistive touch screen +USB cable | ||
5.6' LCD module + 4-wire resistive touch screen +USB cable | |||
6.4' LCD + 4-wire resistive touch screen + USB cable + inverter | |||
7' LCD module + 4-wire resistive touch screen +USB cable | |||
8' LCD module + 4-wire resistive touch screen + USB cable | |||
10.4' LCD+ 4-wire resistive touch screen + USB cable + inverter | |||
Module options | TTL to LVDS module | ||
TTL to VGA module | |||
Sales hotline | +86-571- 89935913 |
High performance ATMEL AT91SAM9263 CPU ARM discovery board Application:
