The cheapest complete wood pellet production line with high yield
complete wood pellet production line is our main product which has adopted the essence of pellet mill in oversea markets. The core part “double layer die” has unique structural assembly and “rollers” are made of high wearable alloymaterials. These two parts have the following characters: particular design, reasonable structure, low energy, high efficiency and long life etc. Through technical experts’ hard work, our company has developed this typical patent product. This new machine has filled the country blank in vertical feeding for ring die pellet mill and reached the international advanced level.
complete wood pellet production line is mainly applicable for materials which is difficult to mold because of low adhesion rate such as:
1.rice husk, sunflower husk, peanut shell and fruit shell;
2. branch, stem, bark and other wood waste; a variety of crop stalks;
3.rubber, cement, ash and other chemical materials.
complete wood pellet production line can be used in feed mill, wood processing plants, fuel plants, fertilizer plants and chemical plants etc. Since it requires less investment but yield quickly with no risk, which means ZLG series efficient centrifugal pellet mill is an ideal dense compression molding equipment.
The advantage of complete wood pellet production line
A. Five characteristics of complete wood pellet production line
1. Vertical feeding.
2. Die is static while roller is rotary; materials are evenly distributed because of the centrifugal force produced by rotary rollers.
3. Double-layer-die. Double layers can be used independently to cut down costs; and two layers of the die also can be used at the same time to improve efficiency and capacity with fewer energy.
4. Ring die and vertical structure are useful in cooling pelletizing room.
5.Independent and frequency conversion discharge device can improve rate of pelleting.
B. Three differences of complete wood pellet production line
1.Upward mould, special structure, vertically feeding which are help to heat: material drop into the pelletizing room vertically with no other auxiliary power device.
Horizontal type ring die pellet mill: the feed inlet and pelletizing room are set in one side, which make light material feeding into the pelletizing room difficultly. So additional force pressing device is needed for feeding; the lifetime of gearing(gear, bearing) is shorten because the pelletizing room couldn’t dissipate heat.
Flat die pellet mill mainly has two structures, though they can be feed vertically but both of these two structures have many disadvantages which are difficult to get rid of:
(1) Die rotates to make pinch rollers running: material is easily arched which lead to uneven feeding.
(2) Rollers rotate while die is static. This could avoid the arching material, but centrifugal force is caused which will swing the material in the pelletizing room to the periphery; and material distributes unevenly which make the center of the flat die with upward pelletizing holes has no material to press.
2. Efficient centrifugal pellet mill: die is static, roller rotates, materials are centrifugal and distributed around evenly one the inner surface of die because of the high rebounding-effect die.
Ring-die pellet mill’s rollers are static and die is rotary so there is no centrifugal force, materials are distributed unevenly.
Flat-die pellet mill’s rollers can rotate to generate centrifugal force, but the directions between die holes and material force are contradictory.
3. Efficient centrifugal complete wood pellet production line :
(1)double-layer die
(2) multi-function
(3)high efficiency: die has upper and lower parts; customers can choose two different aperture within one die to produce different specifications of pellets. When pelletizing easy bonding materials, we can heighten the rollers and use two-layer dies to get four-fold capacity. No flat die or ring die pellet mill can do this.
Technical data of complete wood pellet production line
Model |
Capacity (kg.h) |
Power (kw) |
Diameter of Pellet(mm) |
Weight (T) |
Dimension (mm) |
ZLG 560 |
1000-1500 |
90 |
4-12 |
6.1 |
2600*1300*2310 |
ZLG 720 |
1500-2500 |
160 |
4-12 |
7.3 |
2910*1300*2410 |
ZLG 860 |
2000-3000 |
220 |
4-12 |
15 |
3380*1480*3180 |
ZLG 920 |
3000-4500 |
315 |
4-12 |
18.5 |
3900*1780*3500 |
ZLG 1050 |
4500-6000 |
315 |
4-12 |
22 |
4200*1850*3600 |
Pictures of complete wood pellet line
Spare parts of complete wood pellet production line
Our complete wood pellet production line
complete wood pellet production line has automatic lubricating system that the grease is injected and filtrated automatically, which can ensure the long time working without stop. It also has dust and cooling system that can reduce the dust during it working and improve the working environment.
complete wood pellet production line have been exported to lots of Europe, South America, Southeast Asia countries, and set agents in Brasil ,Canada, Germany, America, South Africa, Australia, India,Vetnam, Malaysia and so on countries.
In order to quote the best price, please let us know the info:
1, What is your raw material?
2,What is the raw material size?
3,What is the raw material moisture content?
4,What is the capacity do you need?
5, Do you need automatic system or manual packing?
If you are interested in this machine, please do not hesitate to contact us.
We are sure that we will offer you the best pellet mill and service.
We are anticipated to cooperate with you.
