Hakko Soldering Iron Tester FG101

Name: Hakko Soldering Iron Tester FG101
Brand: Hakko
SKU: 106968625
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Japan

Brand Name:

Hakko

Model Number:

FG101

Shenzhen Eles Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen/GZ/HK

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Japan

Brand Name Hakko

Model Number FG101

Usage Industrial

Theory Temperature Sensor

Model Name	HAKKO FG-101
Temperature	Resolution	1ºC(1ºF)
	Measurement Range	0 - 700ºC (32 - 1300ºF)^*1
	Precision	±3ºC (between 300 and 600ºC)/ ±6ºF (between 572 and 1112ºF) ±5ºC/10ºF (other than above)
	Sensor	K (CA) type thermocouple
Voltage	Resolution	0.1mV
	Measurement Range	0 to 40mV (AC)
	Precision	± (5% of reading +1 digit)
Registance	Resolution	0.1Ω
	Measurement Range	0 to 40Ω
	Precision	± (5% of reading +1 digit)
Display	LCD	3 1/2 digits

	Burnout^*2
	MAX HOLD	(Refer to "MAX HOLD function.")
Power Consumption	100V-2.6W, 110V-2.9W, 120V-2.6W, 220V-2.7W, 230V-2.8W, 240V-3.0W
Dimensions	200(W)x50(H)x120(D) mm / 7.9(W)x2.0(H)x4.7(D) in
Weight	1kg
Ambient Temperature/ Humidity Range	0 - 40ºC (32 - 104ºF), 20 - 90%RH (Non condensation)
Environmental Condition	Applicable rated pollution degree 2 (According to IEC/UL61010-1)
^1 Temperature sensor (191-212) can only be used to measure temperatures below 500ºC (932ºF). To measure higher temperatures, use an applicable temperature probe When the tip is not in contact with the conduction plate. ^2 When a sensor is not attached nor burns out, an alarm symbol of Burnout is displayed. If this alarm occurs, replace/attach with a new sensor. The same alarm symbol is also displayed when a value over the possible measurement range is detected.
