Universal Testing Machine bending testing machine
- 10 Piece / Pieces per Month
- shanghia ningbo shenzhen
- T/T Credit Card PayPal
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | JIEBO | Model Number: | WDW-50 |
Power: | Electronic | Usage: | Universal Testing Machine |
Product Description
Universal Testing Machine bending testing machine
Ⅰ,Main Functions:
WDW series are suitable for tensile, compression, bending ,cutting, shearing and tearing test of rubber, plastic, electrical wire and cable, composite, plastic profiled bar, waterproof roll, etc. They may add test methods or rules according to customers’requirement .They are essential testing instrument for quality testing section, university and college, research institution and industrial and mining enterprise.
Ⅱ,Product Features
1,This machine equips alternating servo motor for driving crosshead and imported photoelectric encoder for displacement measure.
2,This machine is accompany with the digital multi-channel closed loop control system which applicates the latest monitoring and control systems with lots of advanced professional and technical development. ,
3,Control software can automatically finger out routine data, such as
tensile modulus of elasticity, extend rate after rupture, non-proportional extend strength RP0.2, etc.
4,It can realize three closed loops control and real time display many testing curves of force-displacement, force-time, and stress-strain. These curves automatically switch. Testing process control and data processing conform to the requirements of GB.
5,This machine has the following performances: Auto zero, auto gear shifting or no subsection, auto indication, auto save, unicontrol or multistep programmed control, auto stop, auto analysis or assistant manual analysis, batch test, testing result statistic, curve select and over load protection. And the machine is beautiful, multifunctional, and operates easily and reliably.
Type parameters | WDW-50 |
Measuring range of force (kn) | 0.1-50 |
Accuracy of testing force | ±1% |
Resolution of force | 1/200000 of maximum force |
Relative error of displacement | ±0.5% |
Resolusion of crosshead displacement measurement | 0.01 mm |
Speed range of crossbeam | 0.01 mm/min-500 mm/min,step less speed regulation and arbitrary setting |
Effective testing space (mm) | 650 |
Power supply | 220V±10%,50Hz 1 kw |
Working environment | 10℃-30℃, |
Main configuration | Alternating servo motor and speed adjustment system, precision photoelectric encoder. |
Overall dimension of host machine (mm) | 850×650×2100 |
Weight (kg) | 400 |
Accessories |
|
