Digital Display Hydraulic Universal Testing Machine
LCD Digital Display Hydraulic Universal Testing Machine is used to a variety of metal materials, tensile, compression, bending, shearing accompanied by increased shear test can be done, can be used as plastic, concrete, cement and other non-metallic materials, compression tests, with simple accessories to complete the chain tape , wire, welding rod, tile's wide range of performance tests and components.This machine adopt under the fuel tank-mounted machine, low profile, light weight, especially for the engineering construction sector. Host:Adopt oil cylinder under mounted type host, stretching space is at the top of host, compression test space is between the at the work table and the crossbar .
Production Summary:
LCD Digital Display Hydraulic Universal Testing Machine is used to a variety of metal materials, tensile,
compression, bending, shearing accompanied by increased shear test can be done, can be used as plastic,
concrete, cement and other non-metallic materials, compression tests, with simple accessories to complete
the chain tape , wire, welding rod, tile's wide range of performance tests and components.This machine adopt
under the fuel tank-mounted machine, low profile, light weight, especially for the engineering construction sector.
Host:
Digital Display Hydraulic Universal Testing Machine adopt oil cylinder under mounted type host,
stretching space is at the top of host,compression test space is between the at the work table and the crossbar.
Transmission System:
Down beam go up and down by the use of motor reducer, chain drive mechanism, vice screw drive, to
achieve tensile, compression of space to adjust.
Hydraulic System:
The oil tank is sucked through the filter screen and be inhaled pump oil ,through the petroleum pipeline of
oil pump transport to oil valve,When the hand wheel to send off the oil, due to the role of oil will push the
piston,the oil from the return pipe to tank, when the hand wheel to open get the oil, then the working fluid
into the fuel tank through the tubing, pressure tubing through and through oil return valve to tank.
Control system:
Electronic force measurement, liquid crystal display test force - time curve, test power, peak test power,
has obvious characteristics of the material yield strength yield the experimental data easy and intuitive;
Through digital button input sample numbers, cross-sectional area, can be directly measured the material
tensile strength, yield strength and other mechanical properties; can query the experimental results, print
(with micro-printer)Through digital button input sample numbers, cross-sectional area, can be directly
measured the material tensile strength, yield strength and other mechanical properties; can query the
experimental results,print (with micro-printer).
Safety Protection Device:
a) When the test force more than 3% of the maximum test force, the overload protection,
oil pump motor shut down.
b) When the piston rises to the upper limit position, stroke protection, pump motor shut down.
Fixture:
Whole set fixtures include:stretch fixture,compression fixture,bending fixture.
Max load |
100kn |
300kn |
600kn |
1000kn |
|||||
Range |
whole journey didn't sub-file ,equivalent 3 grade |
||||||||
Test force measuring range |
4%-100%FSKN |
||||||||
Test Force showed the relative error |
≤indicating value±1% |
||||||||
Test Force Resolution |
0.01KN |
||||||||
Displacement measurement resolution |
0.01mm |
||||||||
Max tensile test space |
550mm |
650mm |
750mm |
||||||
Max compression space |
380mm |
460mm |
|||||||
Diameter of round specimen clamp jaw |
Φ6-Φ26m |
Φ13-Φ40mm |
|||||||
Thickness of flat specimen clamping jaws |
0- |
0-15/15-30mm |
|||||||
Maximum clamping width of the flat specimen |
70mm |
75mm |
|||||||
Maximum clamping width of the flat specimen(Column number) |
2 |
2/4 |
|||||||
Clamping method |
Manual clamping |
Automatic clamping/Manual clamping |
|||||||
Shear specimen diameter |
10mm |
||||||||
Upper and lower compression plate size |
Φ160(option 204×204)mm |
||||||||
The maximum distance between the fulcrum bending |
450 |
||||||||
Space stretching from the two pillars distance |
450 |
550 |
|||||||
Pump motor power |
1.1KW |
||||||||
Beam moves up and down motor fixed rate |
0.75KW |
||||||||
Net weight |
1600kg |
1800kg |
2000kg |
2600kg |
|||||
Digital Display Hydraulic Universal Testing Machine
