High frequency 400HZ Army power supply AC400 series three-phase 15kVA

Model

13030

13060

13100

33150

33200

33300

33450

33600

333000

Capacity

3KVA

6KVA

10KVA

15KVA

20KVA

30KVA

45KVA

60KVA

300KVA

Circuit mode

IGBT/SPWM pulse width adjustment mode

Output frequency

400Hz/300~500Hz

Load stability

≤±1%

frequency stability

≤±0.01%

Input voltage

220V±20%

380V±20%

Input phase

Single phase

Tree phase

Three phase unbalance

Phase 120°±2°; phase difference <3% rating value

Wave distortion

THD≤2%

Output voltage

three phase four wires:115V(200V)±20% or 21V(36V) ±20%

Reaction time

≤2mS

Ammeter display

Frequency, voltage, current, power or PF 4 number display

Protection function

over voltage, over current, over temperature, over load, short circuit, and automatic alarm

Insulation reactance

500Vdc 20MΩ

Pressure endurance insulation

1800Vac/5mA/1minute

Cooling method

Compulsive fan cooling

Working temperature

-28°C-60°C

Relative humidity

0-90%(No condensing)

Altitude

1500meters

Dimension (W×L×H)mm

660×400×800

830×450×1100

520×1160×1370

1850×1100×1750
