Hybrid Inverter BNSA-20KS(two Inputs)

Hybrid Inverter BNSA-20KS(two Inputs) thumbnail-1
Hybrid Inverter BNSA-20KS(two Inputs) photo-1
US$ 4,000 - 6,000 MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
BOS
Model Number:
Hybrid inverter BNSA-20KS(two inputs)
Contact Supplier Request Quote Chat Now
Shandong BOS Energy Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name BOS
Model Number Hybrid inverter BNSA-20KS(two inputs)
Output Power 1 - 50W
Output Type Triple
Size 660*610*1560mm
Weight 380KG
Input Voltage 450Vdc-780Vdc 380Vac±15%
Output Voltage 380Vac±2%
Type DC/AC Inverters
Output Frequency 50Hz±1%
Output Current 53A

Specifications

Hybrid inverter BNSA-20KS(two inputs) has two inputs one is solar power ,another is utility grid for bypass,high efficiency

Function feature:

Two inputs:one input is solar power ,another is utility grid for bypass,But solar power is first

Hybrid inverter BNSA-20KS(two inputs)

Model

BNSA-20KS

isolation model

low frequency isolation

input No.

two inputs

input1   input solar power range

450Vdc-780Vdc

input2   input utility grid range

380Vac±15%

rated capacity

20KW

overload ability

150% 10s

rated output voltage

380Vac±2% 3phase 4 wire

rated output frequency

50Hz±1%

Wave distortion rate(THD)

<3%(at rated power)

power factor

>0.8(at rated power)

Max. efficiency

94%

protect function

Protection for input connecting contrary, input lack of voltage, output overload, output short circuit, over load

communication terminal

RS485

working temperature

-20°C~+50°C

humidity

0~95%

humidity

4000m(over 2000s,will derate using)

cooling mode

forced cooling

noisy

≤60dB

protect class

IP20(indoor)

Dimension W*D*H(mm)

660*610*1560mm

Weight(kg)

380
