Home > Products > FREQUENCY CONVERTER > 200kva frequency inverter
200kva frequency inverter
- 1000 Set / Sets per Month
- Qingdao
Product Details
Place of Origin: | Shandong, China | Brand Name: | BOS | Model Number: | AC60-338000 |
Input Voltage: | 380Vac±20% | Output Voltage: | 0~500Vac | Output Power: | 800kw |
Output Frequency: | 45~65hz | Output Current: | 200~1000A |
Product Description
Specifications
200kva frequency inverter:1.CE
2.AC~DC ~AC
3.IGBT
200kva frequency inverter:
AC60 series power is a power that change the electric supply into the required voltage and frequency through power converting circuit.Its main characteristic is to supply prue and stable sine wave power output,low harmonic distortion,high-stability frequency and regulation.It can impersonate many of the world of frequency voltage and output characteristics,and cover the whole industry needs,entirely consistent with the design engineer in research and production and testing of the product testing and life, and a simulated tests to a low, import equipment and the production of electricity and other applications.In addition, it will also support the air space and military equipment 400hz.
Frequency converter 3phase technic parameter
model | 13060 | 13100 | 33150 | 33200 | 33300 | 33450 | 33600 | 331000 | 331500 | 333000 | 334500 | 336000 | 338000 | |||||||
Capacity | 6 KVA | 10 KVA | 15 KVA | 20 KVA | 30 KVA | 45 KVA | 60 KVA | 100 KVA | 150 KVA | 300 KVA | 450 KVA | 600 KVA | 800 KVA | |||||||
Output limit currency | L:16.8A | L:27.6A | L:41.6A | L: 56A | L: 84A | L: 126A | L: 168A | L: 276A | L: 400A | No | ||||||||||
H:8.4A | H:13.8A | H:20.8A | H: 28A | H: 42A | H: 63A | H: 84A | H: 138A | H: 200A | H: 400A | H: 600A | H: 800A | H: 1050A | ||||||||
Circuit model | IGBT/SPWM Pulse width adjustment mode | |||||||||||||||||||
Output frequency | 45-65/50 or 60Hz | |||||||||||||||||||
Load stability | ≤±1% | |||||||||||||||||||
frequency stability | fixed-frequency≤±0.01%,frequency modulation≤±0.1% | |||||||||||||||||||
Input voltage | 220/230/240V/±10% | 380/400/440V±10% | ||||||||||||||||||
Phase | singlephase | three phase four wire | ||||||||||||||||||
3phase unbalanced | Phase position120°±2° ; phase separation<3%rating value | |||||||||||||||||||
Wave distortion | THD≤3% | |||||||||||||||||||
Output voltage | Wire voltage:low-grade:0-260Vcontinuous-tuning,high-grade:0-520Vcontinuous-tuning phase voltage:low-grade:0-150V continuous-tuning,high-grade:0-300Vcontinuous-tuning | |||||||||||||||||||
reaction time | ≤2mS | |||||||||||||||||||
Ammeter display | Frequency, voltage, current, power or PF 4 number display | |||||||||||||||||||
Protection function | Over voltage, over current, over temperature, over load, short circuit, and automatic alarm. | |||||||||||||||||||
Insulation reactance | 500Vdc 20MΩ | |||||||||||||||||||
Pressure endurance insulation | 1800Vac/5mA/1minute | |||||||||||||||||||
Cooling model | Compulsive fan cooling | |||||||||||||||||||
Working temperature | -10°C-50°C | |||||||||||||||||||
Relative humidity | 0-90%(Non-condensing) | |||||||||||||||||||
Altitude | 1500 meters | |||||||||||||||||||
Dimension(W×L×H) mm | 660× 400× 700 | 830×450×1100 | 1160×520×1370 | 1320×600×1490 | 850×1450×1880 | 1160×1910×1880 | 1260×2000×1880 | 830×3260×2260 |
