15kva 400hz Frequency Converter

15kva 400hz Frequency Converter thumbnail-1
15kva 400hz Frequency Converter photo-1
US$ 1,000 - 10,000 MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
BOS
Model Number:
AC40-3301000
Contact Supplier Request Quote Chat Now
Shandong BOS Energy Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name BOS
Model Number AC40-3301000
Output Power Other, 100kva
Output Type Triple
Size 600*1320*1440
Weight 800kg
Input Voltage 320~460Vac
Output Voltage 0~500Vac
Type DC/AC Inverters
Output Frequency 400hz
Output Current 500A

Specifications

15kva 400hz frequency converter
1.Mitsubishi IGBT
2.AC~DC~AC
3.optional DSP control
nnected in parallel

400hz frequency converter



This kind of products adopts special paten technique and high-frequency electron switch change technique. It is specially used for aviation and military electric equipment, such as plane and its carried equipments, radar, navigation, and so on. It is the substitute of the unit frequency conversion power supply. There are ±20% adjustment in voltage and frequency, also it is applied to laboratory and product line as debugging power supply. We can design any products according to the requirement of the clients between 25-1500Hz.

The industry advanced technology:
 AC parallel redundant technique

     Self-developed AC parallel redundant technique makes two or more inverted power supply parallel output, and enhances system reliability.when one set failure,will not affect the normal power supply.Advanced flow equalization technology makes each inverted power supply loading the source of current,to extend the power supply capacity,reduce operation costs and  extend the power lifespan.
Three-phase independently adjustable inverter technique

     Three-phase independently adjustable inverter technique is using three single-phase bridge to exchange,then combines the output by 1200 phase diffience, the three single-phase inverters work independently,so three-phase output not affects each other, can takes 100%unbalance load.

Frequency doubling inverter technology
     Adopting frequency doubling inverter technology makes large IGBT work in the lower frequency, and can greatly reduce heating power and improve reliability. At the same time, compared with the same frequency inverting circuit,the filter parameter decreased fivefold,and the filter greatly reduce the volume,dynamic corresponding faster,so sharply changes the speed of response quicker,output stability,greater output precision.

400HZ frequency converter 1phase technic parameter

Model

11005

11010

11030

11050

31100

31150

31200

31300

31450

31600

311000

capacity

0.5VA

1KVA

3KVA

5KVA

10KVA

15KVA

20KVA

30KVA

45KVA

60KVA

100KVA

Circuit mode

IGBT/SPWM Pulse width adjustment mode

Output frequency

400Hz/300~500Hz

Load stability

≤±1%

Frequency stability

≤±0.01%

Input voltage

220V±20%

380V±20%

Input phase

1phase

3phase4wires

Wave distortion

THD≤2%

Output voltage

115V ±20%

Reaction time

≤2mS

Meter Display

Frequency,voltage,current,power,power factor 4 number display

Protection function

Over voltage, over current, over temperature, over load, short circuit, and automatic alarm.

Insulation reactance

500Vdc 20MΩ

Pressure endurance insulation

1800Vac/5mA/1minute

Cooling mode

Compulsive fan cooling

Working temperature

-28°C-60°C

Relative humidity

0-90%(Ungrumous state)

Altitude

1500meters

Dimension(W×L×H)mm

410×440×140

450×440×222

560×350×670

660×400×800

830×450×1100

520×1160×1370





400HZ frequency converter 3phase technic parameter



Model

13030

13060

13100

33150

33200

33300

33450

33600

331000

331500

333000

Capacity

3KVA

6KVA

10KVA

15KVA

20KVA

30KVA

45KVA

60 KVA

100KVA

150KVA

300KVA

Circuit mode

IGBT/SPWM

Output frequency

400Hz/300~500Hz

Load stability

≤±1%

Frequency stability

≤±0.01%

Input voltage

230V±20%

400V±20%

Input phase

1phase

3phase 4wires

three phases imbalance.

phase120°±2° ;phase difference<3% rated value

Wave distortion

THD≤2%

Output voltage

3phase 4wires ;115V(200V)±20% or 21V(36V)±20%

Protection function

≤2mS

Meter Display

Frequency,voltage,current,power,power factor 4 number display

Protection function

Over voltage, over current, over temperature, over load, short circuit, and automatic alarm.

Insulation reactance

500Vdc 20MΩ

Pressure endurance insulation

1800Vac/5mA/1 minute

Cooling mode

Compulsive fan cooling

Working temperature

-28°C-60°C

Relative humidity

0-90%(Ungrumous state)

Altitude

1500 meters

Dimension(W×L×H)mm

660×400×800

830×450×1100

520×1160×1370

600×1320×1440

1850×1100

×1750



 15kva 400hz frequency converter15kva 400hz frequency converter
