Frequency Converter

Frequency Converter thumbnail-1
Frequency Converter photo-1
US$ 1,000 - 10,000 MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
BOS
Model Number:
AC60-338000
Contact Supplier Request Quote Chat Now
Shandong BOS Energy Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name BOS
Model Number AC60-338000
Output Power Other, 800kva
Output Type Triple
Size 830*3260*2260
Weight 1600kg
Input Voltage 320~460Vac
Output Voltage 0~500Vac
Type DC/AC Inverters
Output Frequency 50/60hz
Output Current 1000A

frequency converter

 AC60 series power is a power that change the electric supply into the required voltage and frequency through power converting circuit.Its main characteristic is to supply prue and stable sine wave power output,low harmonic distortion,high-stability frequency and regulation.It can impersonate many of the world of frequency voltage and output characteristics,and cover the whole industry needs,entirely consistent with the design engineer in research and production and testing of the product testing and life, and a simulated tests to a low, import equipment and the production of electricity and other applications.In addition, it will also support the air space and military equipment 400hz

.

model

11005

11010

11030

11050

31100

31150

31200

31300

31450

31600

311000

Capacity

500VA

1KVA

3KVA

5KVA

10KVA

15KVA

20KVA

30KVA

45KVA

60KVA

100KVA

Output limit currency

L:

4.2A

L:

8.4A

L:

24A

L:

42A

L:

84A

L:

126A

L:

168A

L:

250A

L:375A

L:

500A

L:

840A

H:

2.1A

H:

4.2A

H:

12A

H:

21A

H:

42A

H:

63A

H:

84A

H:125A

H:

188A

H:

250A

H:

420A

Circuit model

IGBT/SPWM Pulse width adjustment mode

Output frequency

50Hz/60Hz/45-65Hz

Load stability

≤±1%

frequency stability

fixed-frequency≤±0.01%,frequency modulation≤±0.1%

Input voltage

220/230/240V±10%

380/400/440V±10%

phase

single phase

three phase four wire

Wave distortion

THD≤3%

Output voltage

low-grade :0-150 V   continuous-tuning ;  high-grade :0 - 300 V  continuous-tuning



reaction time

≤2mS

Ammeter display

Frequency, voltage, current, power or PF 4 number display

Protection function

Over voltage, over current, over temperature, over load, short circuit, and automatic alarm.

Insulation reactance

500Vdc 20MΩ

Pressure endurance insulation

1800Vac/5mA/1minute

Cooling model

Compulsive fan cooling

Working temperature

-10°C-50°C

Relative humidity

0-90%(Non-condensing)

Altitude

1500meters

Dimension(W×L×H) mm

410×440×135

450×

440×

222

560×

350×

600

660×

400×

700

830×450×1100

1160×520×1370

 frequency converterfrequency converter
