6KVA AC Frequency Converter Power Source AC60-13060

FOB Price

USD $1,400 - $2,160 / Set

10 Sets(Min.Order)

Supply Ability 500 Set / Sets per Month
Port Qingdao

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Shandong, China	Brand Name:	BOS	Model Number:	AC60-13060
Output Power:	1 - 200KW	Output Type:	Triple	Size:	660400700
Weight:	50KG	Input Voltage:	220V/±10%	Output Voltage:	low-grade:0-150V high-grade:0 - 300 V
Type:	Other, AC/AC converter	Output Frequency:	50Hz/60Hz/45-65Hz	Output Current:	8.4A-16.8A

Product Description

Specifications

6KVA AC Frequency Converter Power Source AC60-13060
with 16 bit microprocessors, the intelligent control and easy operation

6KVA AC Frequency Converter Power Source AC60-13060

Features:

1.Have a high voltage, over current and short-circuit and overheat warning device
2.16 bit microprocessors, the intelligent control and easy operation
3.Low distortion interference,input and output are completely isolated , safe and reliable
4.Unique transient waveforms value control and low distortion, high precision control
5.Dynamic quick,when load changgees in 0 - 100% ,stationary response time <0.1S
6.Provide world standard grid voltage,frequency,simulation testing all kinds of electrical products
7.With no radiation,small harmonic ingredients and special treatment,no distracting
8.The efficient up to above 85% wide applicable load,can be perceptual capacitive resistive load
9.Import original german siemens IGBT high frequency inverter and deck mechanism
10.Output voltage:low-grade:0-150 V,high grade: 0-300V adjustable continuously
11.A machine has more function,surface and source are one:with the nearest 0.5 level output voltage, current and frequency and power the power factor watch

Technical parameters:

Model	13060
Capacity	6KVA
Phase current	L:16.8A
Phase current	H:8.4A
Circuit model	IGBT/SPWM pulse width adjustment mode
Output frequency	45-65/50 or 60Hz
Load stability	≤±1%
frequency stability	fixed-frequency≤±0.01%,frequency modulation≤±0.1%
Input voltage	220V/±10%
Phase	Single phase
Three phase unbalance	Phase120°±2°; phase difference<3%rating value
Wave distortion	THD≤2%
Output voltage	Wire voltage:low-grade:0-260V continuous-tuning,high-grade:0-520Vcontinuous-tuning Phase voltage:low-grade:0-150V continuous-tuning; high-grade:0 - 300 V continuous-tuning
Reaction time	≤2mS
Ammeter display	Frequency, voltage, current, power or PF 4 number display
Protection function	over voltage, over current, over temperature, over load, short circuit, and automatic alarm
Insulation reactance	500Vdc 20MΩ
Pressure endurance	1800Vac/5mA/1minute
Cooling method	Compulsive fan cooling
Working temperature	-10°C-50°C
Relative humidity	0-90%(No condensing)
Altitude	1500meters
Dimension (W×L×H) mm	660×400×700
