Specifications
PVC PET PC film screen printing machinePVC PET PC film screen printing machine
Features:
This machine is composed of printer part, take-off machine and UV dryer. It is a 3/4 automatic production line which feeds material to printer by human hand, then takes off material automatically. After printing arm and printing table, suck and pull out the printing material, then send it to nest working procedure (drying and paper collecting). It can not only save human labor, but also improve working efficiency of printing machines. It is fit for printing on flexible material such as paper and polyster plastic film and so on.
Parameters:
Model | SFB750N | SFB960N | SFB1270N |
Max.Printing size | 700x500mm | 900x600mm | 1200x700mm |
Working table size | 900x600mm | 1100x700mm | 1300x800mm |
Paper Size | 720mm(Width), Equal or less than 500GSM | ||
Working Air pressure | 0.3-0.6mpa | ||
UV lamp | 5.6kw x 2pcs | ||
Belt width of UV dryer | 760mm | ||
Power of UV dryer | 12.5kw | ||
Total power | 16kw |
|
|
Voltage | 380V 50HZ,15.5KW | 380V,50HZ,16.5KW | 380V 50HZ,17KW |
Machine overall size (mm) | 6800x1050x1540 | 6800x1180x1700 | 6900x1400x1850 |
