Technical Specification:
Model | SPO-6/24 | SPO-8/30 | SPO-10/36 | SPO-12/42 | SPO-14/48 |
Print Color | 6 | 8 | 10 | 12 | 14 |
Stations | 24 | 30 | 36 | 42 | 48 |
Max Print Area | 500×750mm | 500×750mm | 500×750mm | 500×750mm | 500×750mm |
Max Pallet Size | 530×950mm | 530×950mm | 530×950mm | 530×950mm | 530×950mm |
Max Frame Size | 600×1000mm | 600×1000mm | 600×1000mm | 600×1000mm | 600×1000mm |
Air Consumption | 6Bar,144L/min | 6Bar,144L/min | 6Bar,144L/min | 6Bar,144L/min | 6Bar,144L/min |
Main Motor Power | 3.0KW | 3.0KW | 3.0KW | 3.0KW | 3.0KW |
Each Print Motor Power | 0.55KW | 0.55KW | 0.55KW | 0.55KW | 0.55KW |
Each Dryer Power | 13.6KW | 13.6KW | 13.6KW | 13.6KW | 13.6KW |
Voltage | AC380V/3PH/50HZ | AC380V/3PH/50HZ | AC380V/3PH/50HZ | AC380V/3PH/50HZ | AC380V/3PH/50HZ |
Dimension | 1122×320×133cm | 1362×320×133cm | 1602×320×133cm | 1842×320×133cm | 2082×320×133cm |
Weight | 2000KG | 2600KG | 3200KG | 3800KG | 4400KG |
Description:
Oval type automatic Screen printing machine is based on rotary screen printing machines,its performance and printing process is very well.The machine adopts modular design, high-strength aluminum alloy structure, the main rotation system adopt high-precision servo drive to assure the fast and stable operation,with the features of accurate printing, reliable performance, easy operation. Suitable for water-based ink, plastisol ink, Solvent ink and other printing processes, standardly configurated with flocking function.It’s best for pieces and various garment printing, and also flocking processing.
Control system:
1.Man-Machine interface and PLC system ,self-diagnosis.
2.Language can be exchanged between Chinese and English by Touch screen , and the help simplifies the process of operation and training.
3.Real-time display of production speed to more clearly control the operating costs.
4.four operation modes: match mode, preheat platen, automatic cycle, single cycle.
Printing platen:
1.Adopt the high strength and high-temperature resisting aerospace aluminum plate
2.Installing and replace is very rapid.
Printing station:
1.Each station can be controlled individually and be operated work or stop easily,also can control the entire equipment ON/OFF.
2.The speed and pressure of squeegee is independently adjustable.
3.Floodbar and squeegee can be fixed and took off without any tools.
4.The stop position of print head can be set freely;
5.AC drive system, stepless speed regulation.
6.Screw adjust position, accuracy±0.05mm
7.Printing times and route can be set free.
Rotating System:
1.Servomotor drive, running precise, high-speed, stable.
2.Multiple speed can be customized according to user demand.
3.Forward and reverse.
Module Expansion:
1.Customers buy the printing machine with the suitable numbers of stations according to demand.
2.For further needs,you can quickly and easily enlarge the machine in every two-station units.
Design & Construction:
1.High-strength, high-precision alloy aluminum structure,simple,lightweight,stable and secure;Enclosed stainless steel countertops ensures the safe operation and easy clean.
2.Modular design makes the site installation quick and future expansion easy.
Sample:
Q1:We are interested in the screen printing machine,Could you quote the latest price to us?
A1: In order to recommend the suitable machine for you ,please provide following information before we quote price:
1.How many color to print will you need?
2.What's your max printing size? (Such as 500x700mm or biger or smaller)
3.What's the capacity per hour you request? (Such as 900pcs/h or more)
Q2:What's the MOQ, Delivery time, and payment terms?
A2: 1. MOQ: 1 set
2. Delivery time: 20 workdays after receiving T/T 30% payment deposit
3. Payment Term: T/T 30% as deposit, T/T 70% before shipment or L/C at sight
1. Warranty
1 year limited warranty after installation.If the spare parts is broken in the warranty
period , we will send a free replacement parts to you .
2. Installation and Training
We can send 1-2 engineers to buyers factory to install and set up the machines and
training, but all the charges for the engineers should be paid by buyer.
3. Quotation
The quotation is available in 60 days
We have a professional transport channel
1.About us
Wenzhou Changs Machinery Co.,Ltd is one of the first company specialized in manufacturing printing machines, packing machines, plastic machine and paper converting machines,has owned export and import license since 2004.
To consider our full service convenience, we have set up service office and showing room at DRAGON-MART of Dubai to provide technical service for customers from Middle East and Africa in 2006, and also we have established technical support offices in Mexco, Egpty and Singapore, our service has satisfied with all of our customers. We enjoy sound reputation in oversea’s market and domestic.
2.Certificate
3. Cooperative partner
