GZ Series automatic vegetable/coconut/olive/lubrication oil bottle filling machine

automatic vegetable oil bottle filling machine

Principle and characteristics:

This type of machine can be used for fixed amount small package filling, straight line type filling,mechamcal,electric,apparatus control of all sorts of viscous and nonviscous,erosive liquid,such as plant oil chemlcal,liquid,daily chemical industry.It is rather simple and rapid to change items,the design is quite distinct,the property is Very advantageous,its appearance corresponds to international concept for mechanlcal equlpment.
It has applied MITSUBISHI PLC computerlzed control,from germany.
It has intellectual,protection function.
Vacuum drop prevention device guarantees there Should be absolutely no drop or leakage during production.
There is a switch for step progressive type suppiy and continuous supply.It can be Set Optionally.
It has applied imported pneumatic control parts.
It has applied German technique on photoelectric sensors.
Nalional patenled double speed technique has greatly increased production effciency.
This machine is suitable for many items,the adjustment is rapid and high efnclent.
Electrlcal volume adjustment System.
Photoelectric inspection system has applid TURCK products of germany.
Can be used together with the cover screwing &pressing machine,Leakage inspection macine,Aluminum foil operang sealing machine.

Technique parameter

Parameter                       Unit                             MODEL SNYG SERIES
Number of heads          PCS                     12                         10                    8                        6                        4
Filling volume                 ML                                               200-6000
Productivity                      BPH                    1600-4000     1400-3200     1200-2600     1000-1900   720-1300
Filling tolerance             %                                                   <0.5%
Power sonsumption     KW                        1.5                      1.5                  1.5                     1.2                     1.0
Gas pressure                 MPA                                           0.55-0.8mpa
Gas consumption          M3/MIN                 1.6                     1.4                   1.2                    1.0                      0.8
