Specifications
1. PPR Pipe Equipment2. High output
3. Reliable performance
4. Pipe are with widely use
5. Competitive price
PP-R Pipe Making Machine/PP-R Pipe Equipment/PP-R Pipe Machinery/Pipe Extruding Machine/PPR Pipe Equipment
Characters and use:
Equipped with polyolefin purposed single-screw extruder, it has the characters of quick extruding, high efficiency and so on.
The specially designed co-extrusion die head is reasonable in flow channel, smooth in both internal and external walls, and small in internal stress.
Pipe diameter is among 20-160mm and production speed reaches to 16m/min.
One unit serves several purposes. It can produce common PP-R, Nanometer anti-bacteria pipe, PE-RT and PE-X.
If added one co-extrusion engine and die on original base, it can produce PP-R fiberglass reinforced composite pipe.
PP-R Pipe Extrusion Machinery
1.Equipped with polyolefin purposed single-screw extruder, it has the characters of quick extruding, high efficiency and so on.
2.The specially designed co-extrusion die head is reasonable in flow channel, smooth in both internal and external walls, and small in internal stress.
3.Pipe diameter is among 20-160mm and production speed reaches to 18m/min.
4.One unit servise several purposes. It can produce common PP-R, PE pipe, and PPR-AL-PPR with some extra machines.
5. CE and ISO certificate, we supply full complete turn-key service
Model |
SJ65/30-33 |
SJ75/30-33 |
SJ90/33 |
Pipe diameter |
20-63 |
20-110 |
20-160 |
Screw size |
65mm,33:1 30:1 |
75mm,33:1 30:1 |
90mm,33:1 |
Extrusion capacity |
120kg/h |
220kg/h |
350Kg/h |
Max extrusion speed |
10m/min |
12m/min |
18m/min |
Install power (kw) |
58 |
85 |
200 |
Main motor (kw) |
37 |
75 |
132 |
Total Length |
20 |
25 |
35 |
The main unit list:
1 |
Mixer |
1 set |
|
2 |
Auto loader and hopper dryer |
1 set |
|
3 |
SJ65, SJ75, SJ90 single screw extruder |
1 set |
|
4 |
SJ25 mark line extruder |
1-2sets |
option |
5 |
Pipe moulds |
1 set |
|
6 |
Vacuum calibrating tank |
1 set |
|
7 |
Water cooling tank |
1-2sets |
option |
8 |
Haul off |
1 set |
|
9 |
Printer |
1 set |
option |
10 |
Cutter |
1 set |
|
11 |
Stacker |
1 set |
