Semi auto paper board creasing and die cutting machine

FOB Price

USD $3,900 - $35,000 / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port Ningbo
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Packaging Material:	Paper	Automatic Grade:	Semi-Automatic
Model Number:	ML-2000

Product Description

Specifications

paper board die cutter
The die cutting and creasing machines are special equipments for die cutting and creasing a w

paper board die cutter

Application
RQ serial die cutting & creasing machines special equipments of die cutting and creasing a wide range of materials, such as cardboard, corrugated board, plastic and leather. They are applicable to the fields of printing, packaging, decoration and plastic industries. RQ machines have been acceptable for the customers from home and abroad, due to their outstanding features, high quality and good service.

* Sliding bearings are made of high quality alloy cooper, thus to get effect of anti-frietion and shake reducing.

* Flywheel is with big moment of force and large pressure.

* High strength due to one piece casting by using top-ranking material for machine body.

* Single plate electromagnetic clutch is sensitive and reliable.

* With functions of single, continuous and opening dweel operation, dwell range is adjustable.

* Operating position is reasonably arranged, moving-bed can be opened to its optimum.

* Central lubrication system guarantees fine lubrication and reduce friction. * Safety system is reliable.

Technical Parameters:

Model	Max.Rule Area (mm)	Working speed(strokes/min)	Max Rule Length	Motor power(kw)	Weight (kg)	Overall Deminsion(LWH) (mm)
ML750	750*520	25±2	<25m	2.2	1900	126014001280
ML930	930*670	23±2	<25m	5	3000	1670*13701630
ML1040	1040*720	21±2	<30m	5.5	4000	180016801600
ML1100	1100*800	20±2	<30m	5.5	4500	190017801700
ML1200	1200*850	18±2	<38m	7.5	6500	200021401940
ML1300	1300*920	18±2	<38m	7.5	6500	200021401940
ML1400	1400*1000	17±2	<38m	7.5	7200	201024001950
ML1500	1500*1100	17±2	<40m	7.5	8500	201024801960
ML1600	1600*1250	16±2	<43m	11	11800	217025602080
ML1700	1700*1280	16±2	<45m	11	12500	217025602100
ML1800	1800*1280	16±2	<50m	11	14200	218027602100
ML2000	2000*1400	16±2	<58m	15	16500	227031002150

creasing and die cutting machine

Contact Us

Wenzhou Changs International: Contact nameSpring Chang; Phone86-577-86051838,86051848,86059; AddressRoom 1105, Guoguang Mansion, Zhanqianxiaoqu, Wenzhou City, Zhejiang Province. China Wenzhou,Zhejiang
