Specifications
Heating and Cooling Mixing Machine1.Double speed motor
2.Can also dry and color the material
3.Self-friction heating
4,lo
SRL-Z series PVC Heating and Cooling Mixing Machine
Application & Apply Range
1,It is apply for mixing ,coloring and drying of various resin such as poly, PE,PP,PVC polypropylene, poly chloride etc., and in the process of drying and volatilization of engineering plastic such as ABC, PC, etc. Berore forming and processing as well in the mixing of phenolic resin.
2. The unit combines heat mixing and cool mixing together. The material after heat mixing can be send into cool mixer for cooling automatically, exhausts remaining gases and avoids agglomerates.
3.The unit is developed by importing ,and absorbing advanced technology. By adopting PLC control ,it features high automatic level, good mixing effect, complete function, compact structure and beautiful appearance. It is an ideal equipment for plastic mixing .
main technical parameter | ||||||
Parameter/model |
SRL-Z50/100A |
SRL-Z100/200A |
SRL-Z200/500A |
SRL-Z300/600A |
SRL-Z500/1000A |
|
Total volume(L) |
50/100 |
110/200 |
200/500 |
300/600 |
500/1000 |
|
Effective volume(L) |
32/75 |
75/160 |
150/320 |
200/360 |
375/640 |
|
Oar speed(rpm) |
750/1500/180 |
650/1300/180 |
475/950/110 |
475/950/110 |
430/260/50 |
|
Motor power(Kw) |
7/11/5.5 |
14/22/5.5 |
30/42/7.5 |
40/55/7.5 |
47/67/11 |
|
Heating & cooling |
Self-friction/water |
|||||
Discharge |
pneumatic |
|||||
weight(T) |
2.2 |
3.2 |
3.5 |
3.8 |
4.2 |
|
