Help CenterCar Rearview Mirror Prevent Mist
Related Products
-
Car Mirror Heater Automobile Rear Mirror Heating Film Anti-foggingUS$ 0.65 - 2MOQ: 2000 Pieces -
High Quality Carbon Fiber Heating WiperUS$ 1.2 - 1.8MOQ: 2000 Pieces
-
Customized Heating Element for Rearview MirrorUS$ 0.35 - 1.15MOQ: 2000 Pieces
-
Battery Powered Temperature Control Heating Element for Rearview MirrorUS$ 0.35 - 1.15MOQ: 2000 Pieces
-
Thin Film Heating Element for Car MirrorUS$ 0.65 - 2MOQ: 500 Pairs
Specification:
Description |
Parameter |
Certification |
CE/ROHS |
Voltage range |
1.5v to 36v |
Power density range |
0.07w/cm2~2.5w/cm2(0.19w/inch2~16.13w/inch2) |
Using temperature range |
-60~200°C(-140~392°F) |
Width range |
10mm~500mm(0.39"~19.68") |
Length range |
10mm~1800mm(0.39"~70.86") |
Thickness range |
Standard:0.126~0.266mm(0.005"~0.01") |
Plug |
Chinese,British, American, European and so on |
Quality guarantee |
1 year |
Life |
more than 4 years(normal useful) |
MOQ |
500 piece |
OEM and ODM is welcome,can print your logo | |
Basic information
1. Insulation: UDC500V>=200M ohm
2. Dielectric strength: UAC>=2000V
3. Operation temperature: <=232C
4. Wattage density: <=1.1W/cm2 or <=6.5W/cm2(with thermostat)
5. Thickness: <=0.2mm Can bent at any angle
6. Weight: <=278g/m2
Primary Competitive Advantages
1. Instruments temperature control: Gyro-accelerating detector, tail-wing operating device, aero-photographic apparatus
2. Medical instruments: Disinfection, keeping blood, injections and drips
3. Test and research: Crystal ovens, mechanically-heated structures, IC testers and flasks
4. Agriculture and animal husbandry: Seedling breeder, raising chicken and pigs, breeding fish, incubators, electric blankets for stock and poultry
5. Transportation: Car mirror and signal defogging, water tank heating
Thin film heating element is long life and the power is stable, the elevation of temperature speed is quick, the energy conservation environmental protection, The material quality is frivolous.
It has many advantages as follow:
1. It is made by metal heating material.
2. It can provide stable power.
3. The minimum thickness is 0.025mm.
4. The resistance, which determines the power, can be regulated by the thickness,width and shape of the film.
5. Based on different requirement of temperature, we can choose various materials about the temperature-resistant isolative flakes.
