Automatic Carbonated Soft Drinks Making Plant
US$ 8,000 - 30,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Cans, Bottles, Barrel
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Carbonated Filling Machine for PET BottleUS$ 8,000 - 30,000MOQ: 1 Set -
Complete Carbonated Drink Production LineUS$ 8,000 - 30,000MOQ: 1 Set
-
XWD12-4 Filling and Capping 2-in -1 MachineUS$ 10,000 - 300,000MOQ: 1 Set
-
XWD20-4 Filling and Capping 2-in -1 MachineUS$ 10,000 - 300,000MOQ: 1 Set
-
Carbonated Drink Bottling Plant for Small BusinessUS$ 8,000 - 30,000MOQ: 1 Set
Condition
New
Application
Beverage
Packaging Type
Cans, Bottles, Barrel
Packaging Material
Plastic, Wood
Automatic Grade
Automatic
Driven Type
Electric
Voltage
380V-600V
Power
5KW
Place of Origin
Jiangsu, China
Brand Name
BE
Model Number
DCGF18-18-6
Dimension(L*W*H)
2300X1800X2300
Weight
3000KG
Certification
CE ISO
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Filling Machine 3 in 1carbonated drink production line
its used for glass bottle /pet bottle
capacity:2000-4000BPH
3 in 1 Carbonated Filling Machine
Filling heads: 18
Capacity :2000~4000BPH (500ml)
External dimension:2200×1800×2500mm
Net weight1: about 2000kg
Filling temperature: 3-5degree
Total power: 4.2KW
machine details
Bottle application: PET bottle
Diameter of bottle body: Φ 50mm —Φ 100mm
Height: 150mm -320mm
Maximum of cap: Φ 40mm
Cap application: plastic
Adjustable form: transducer
Power of Cap unscramble: 0.37kw
Pressure of water supplier: >0.06MPa <0.2Mpa
Height of liquid in slot: 1 -2.5m
Air supplier: >0.5MPa
The pressure of compressor in carbonated drinks: 3MPA
more type
| Model | CGFD16126 | CGFD18186 | CGFD24248 | CGFD32328 | CGFD404010 | CGFD505012 | CGFD 606015 | CGFD808020 |
| Filler/Capper heads | 16-12-6 | 18-18-6 | 24-24-8 | 32-32-8 | 40-40-10 | 50-50-12 | 60-60-15 | 80-80-20 |
| Bottle diameter(mm) | φ=50-100 H=170 330-1500ML | φ=50-110 H=160-340 | ||||||
| Production capacity(350ml)(b/h) | 2000-4000 | 4000-6000 | 8000-10000 | 10000-12500 | 12500-15000 | 16000-20000 | 20000-24000 | 26000-32000 |
| Filling temperature ºC | 0-5 | |||||||
| Filler type | Balanced pressure filler | |||||||
| Spraying pressure(Mpa) | 0.2-0.25 | |||||||
| Filling pressure(Mpa) | 0.15-0.35 | 0.2-0.4 | ||||||
| Motor power(kw) | 2.2+0.55+0.12 | 2.2+0.55+0.18 | 3+0.55+0.18 | 5.5+0.55+0.18 | 7.5 | 11 | 15 | 19 |
| Overall dimension (L*W*H)mm | 2300*1600*2500 | 2600*1920*2550 | 3100*2200*2800 | 3850*3000*2850 | 4850*3800*2750 | 5750*3550*2750 | 6500*5500*2750 | 7680*6640*2650 |
| Weight(kg) | 2800 | 3650 | 4800 | 6800 | 8650 | 10500 | 12800 | 15000 |
PICTURES
machine for process:
