Specifications
pet bottle soda machinecarbonated drink production line
its used for glass bottle /pet bottle
capacity:2000-4000BPH
PET BOTTLE carbonated drinks MACHINE
Filling heads: 18
Capacity :2000~4000BPH (500ml)
External dimension:2200×1800×2500mm
Net weight1: about 2000kg
Filling temperature: 3-5degree
Total power: 4.2KW
Bottle application: PET bottle
Diameter of bottle body: Φ 50mm —Φ 100mm
Height: 150mm -320mm
Maximum of cap: Φ 40mm
Cap application: plastic
Adjustable form: transducer
Power of Cap unscramble: 0.37kw
Pressure of water supplier: >0.06MPa <0.2Mpa
Height of liquid in slot: 1 -2.5m
Air supplier: >0.5MPa
The pressure of compressor in carbonated drinks: 3MPA
automatic 3-in-1 soda water machines/soda bottling equipment
main parameters:
Model: | DCGF18-18-6 | DCGF24-24-8 | DCGF32-32-12 | DCGF40-40-12 | ||
Capacity :500ml | 5000 | 8000 | 12000 | 15000 | ||
Bottle shape: | roud or square | |||||
PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm | |||||
Cap: | PE srew cap | |||||
Filling precision: | ≤±5mm | |||||
Filling pressure:(Mpa) | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | 0.15-0.35 | ||
Rinsing pressure:(Mpa) | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | 0.2-0.25 | ||
Filling volume :(L) | 3.5 | 4 | 6 | 8 | ||
Overall size:(mm) | 2450*1800 | 2780*2200 | 3600*2650 | 3800*2950 | ||
Weight: (kg) | 3500 | 4500 | 5500 | 6500 | ||
PICTURES
