Help CenterSubmersible Mixer
US$ 500 - 1,000
MOQ: 5 Units
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Model Number:
QJB
Theory:
Jet Pump
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Model Number
QJB
Theory
Jet Pump
Structure
Multistage Pump
Usage
Water
Power
Electric
Standard or Nonstandard
Standard
Fuel
Other
Pressure
Low Pressure
Application
Submersible
Detailed Product Description
1.Two independent mechanical seals
2.High efficiency, self-cleaning function
3.High efficiency, self-cleaning function
Product Overview
QJBsubmersible mixer as a water treatment process is one of the key equipment in the water treatment process, the biochemical processes can be realized in solid-liquid two-phase flow and homogeneous solid-liquid-gas flow, the flow of process requirements. It consists of submersible motor, impeller and mounting system, etc.
QJBsubmersible mixer as a water treatment process is one of the key equipment in the water treatment process, the biochemical processes can be realized in solid-liquid two-phase flow and homogeneous solid-liquid-gas flow, the flow of process requirements. It consists of submersible motor, impeller and mounting system, etc.
Applications
Stirring to create a flow for the month, to improve water quality, increase oxygen content in water, effectively prevent the deposition of suspended solids
Conditions of Use
In order to ensure the normal to make diving mixer, please select the correct working environment and operating mode.
Maximum medium temperature does not exceed 40 degrees; and PH range: 5-9;
Medium density not exceeding 1150Kg / m 'diving deeper than 10m.
Mixer must be fully submerged underwater diving work, not flammable and corrosive and high temperature environments
Conditions of Use
In order to ensure the normal to make diving mixer, please select the correct working environment and operating mode.
Maximum medium temperature does not exceed 40 degrees; and PH range: 5-9;
Medium density not exceeding 1150Kg / m 'diving deeper than 10m.
Mixer must be fully submerged underwater diving work, not flammable and corrosive and high temperature environments
Specific parameter
| Model | Motor power (kw) |
Rated current (A) |
rpm of impeller(r/min) |
Diameter of impeller(mm) |
Thrust (N) |
Weight (KG) |
| QJB220/960-0.37/S | 0.37 | 1.12 | 960 | 220 | 138 | 45/50 |
| QJB220/1400-0.55/S | 0.55 | 1.35 | 1400 | 220 | 145 | 45/50 |
| QJB260/740-0.85/C/S | 0.85 | 3.2 | 740 | 260 | 163 | 55/65 |
| QJB260/960-1.5/C/S | 1.5 | 4 | 960 | 260 | 290 | 55/65 |
| QJB320/740-2.2/C/S | 2.2 | 5.9 | 740 | 320 | 582 | 88/93 |
| QJB320/960-4/C/S | 4 | 10.3 | 960 | 320 | 609 | 88/93 |
| QJB400/740-1.5/C/S | 1.5 | 5.2 | 740 | 400 | 600 | 74/82 |
| QJB400/740-2.5/C/S | 2.5 | 7 | 740 | 400 | 800 | 74/82 |
| QJB400/740-3/C/S | 3 | 8.6 | 740 | 400 | 920 | 74/82 |
| QJB400/960-4/C/S | 4 | 10.3 | 960 | 400 | 1200 | 74/82 |
| QJB620/480-4/S | 4 | 14 | 480 | 620 | 1400 | 190/206 |
| QJB620/480-5/S | 5 | 18.2 | 480 | 620 | 1800 | 196/212 |
| QJB620/480-7.5/S | 7.5 | 28 | 480 | 620 | 2600 | 240/256 |
| QJB620/480-10/S | 10 | 32 | 480 | 620 | 3300 | 250/266 |
| QJB560/740-11/S | 11 | 25 | 740 | 560 | 2900 | 194/209 |
| QJB560/740-15/S | 15 | 34 | 740 | 560 | 3460 | 260/275 |
| QJB740/740-18.5/S | 18.5 | 41 | 740 | 740 | 4200 | 276/294 |
| QJB740/740-22/S | 22 | 47.4 | 740 | 740 | 5400 | 292/310 |
| QJB620/480-5.5/S | 5.5 | 11 | 480 | 620 | 1800 | 160/176 |
| QJB620/480-7.5/S | 7.5 | 15 | 480 | 620 | 2600 | 182/198 |
| QJB620/480-11/S | 11 | 22 | 480 | 620 | 3300 | 224/240 |
| QJB740/235-15/S | 15 | 30 | 235 | 740 | 3680 | 288/306 |
| QJB890/326-18.5/S | 18.5 | 36 | 326 | 890 | 4600 | 364/382 |
| QJB890/326-22/S | 22 | 42 | 326 | 890 | 5760 | 380/398 |
