Power Inverter 3000Watt From Chinese Manufacturer Thinkpower GOOD QUALITY WITH GOOD PRICE
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Thinkpower
Model Number:
T3000TL
Payment & Shipping
Payment Methods:
Port of Shipment:
Shangahi
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Chinese Manufacturer Thinkpower Providing Good Quality Solar Power Inverter 3000WattNegotiableMOQ: 1 Piece -
Wholesale and Retail 3000Watt Smart Dc/ac Solar Power Inverter China Grid Tie Inverter Full Digital ControlNegotiableMOQ: 1 Piece
-
Chinese Manufacturer Thinkpower Solar Power Inverter 1KW With Wifi MonitorNegotiableMOQ: 1 Piece
-
Thinkpower Solar Inverter 2KW MAX.DC Power 2500W With WIFI the Best Parter of PV SystemNegotiableMOQ: 1 Piece
-
AUSTRALIA 2200W Solar Inverter With WIFI Monitor SAA CE VDE G83 G59 CQCNegotiableMOQ: 5 Pieces
Place of Origin
Jiangsu, China
Brand Name
Thinkpower
Model Number
T3000TL
Output Power
Other, 3000-3300W
Output Type
Single
Size
375*480*136MM
Weight
18KG
Input Voltage
75-550V
Output Voltage
08,220,230, 240/180~265
Type
DC/AC Inverters
Output Frequency
50,60/±4.5 auto-selection
Output Current
17A
Specifications
Power Inverter 3000Watt from Chinese Manufacturer Thinkpower .We promise GOOD QUALITY WITH GOOD PRICE.OUR PRODUCTS: Thinkpower T3000TL PV Grid-connected Inverters
| Model No | T1500TL | T2200TL | T3000TL |
| DC side/Input parameters | |||
| Max. DC power [W] | 1800 | 2500 | 3400 |
| Max. DC voltage [Vdc] | 450 | 500 | 550 |
| Min. System start/Shut down voltage [Vdc] | 150/100 | 150/100 | 150/100 |
| MPPT voltage range[Vdc] | 100~450 | 100~500 | 100~550 |
| Max. input current [A] | 10 | 13 | 15 |
| Number of MPP trackers | 1 | 1 | 1 |
| AC side/output parameters | |||
| Nominal output power [W] | 1500 | 2200 | 3000 |
| Maximum output power [W] | 1650 | 2420 | 3300 |
| Nominal output voltage/range [V] | 208,220,230, 240/180~265 |
208,220,230, 240/180~265 |
208,220,230, 240/180~265 |
| AC grid frequency/range [Hz] | 50,60/±4.5 auto-selection |
50,60/±4.5 auto-selection |
50,60/±4.5 auto-selection |
| Maximum output current [A] | 8 | 12 | 17 |
| AC connection(with PE) | Single phase | Single phase | Single phase |
| Current distortion(THDi) [%] | <1.5 | <1.5 | <1.5 |
| Power factor [%] | More than 99.9 | More than 99.9 | More than 99.9 |
| Efficiency | |||
| Maximum conversion efficiency[%] | 97.3 | 97.4 | 97.5 |
| European efficiency[%] | 97 | 97.1 | 97.2 |
| MPPT efficiency[%] | 99.9 | 99.9 | 99.9 |
| Protection | |||
| DC reverse-polarity protection | yes | yes | yes |
| Short circuit protection | yes | yes | yes |
| Ground fault/residential current monitoring | yes | yes | yes |
| Grid monitoring | yes | yes | yes |
| DC/AC side varistors(thermally protected) | yes | yes | yes |
| General Parameters | |||
| Dimension(L/W/H)[mm] | 375*480*136 | ||
| Weight(kg) | 14.5 15 15.6 | ||
| Embedded DC Switch | Optional | ||
| Night Mode support | Optional | ||
| Night power consumption[W] | < 0.2 | ||
| Isolation type | Transformerless | ||
| Protection degree | IP65 | ||
| Operation temperature[ºC] | -25~60 | ||
| Heat Dissipation | Convection | ||
| Acoustic noise level[dB] | <25 | ||
| Altitude[m] | <2000 without power derating | ||
| Storage temperature[ºC] | -30 ~ 80 | ||
| Real Time Clock module | yes | ||
| LCD Display | Graphic and digital segment | ||
| Communication Interface | Standard WiFi | ||
| Certificates | CE,VDE4105,G83,G59,SAA,CQC | ||
|
Warranty: 5/10/15years yes/optional/optional/optional* More technical characteristics are avaliable on demand and customized. | |||
