Specifications
Chinese Manufacturer Providing Good Quality Solar Power Inverter 3000Watt,with high efficiency 97.5% and good MPPT trackerThinkpower T3000TL (3000Watt) PV Grid-connected Inverter
Certificates: CE,VDE4105,G83,G59,SAA,CQC
Thinkpower Inverter Features
u Digital control chip same as SMA’ second generation is from TI (U.S.). With this digital technology, even in the face of abnormal change of power grid or external interferences, the internal system can automatically screen and adjust, to maximize compatible grid and maintain the PV system stability;
u Thinkpower has achieved relevant certificates, such as VDE4105(German), SAA(Australia), G59(UK), G83(UK), CE 62109-1&2(European) and EMC(European). Moreover it has some frontier functions such as automatically outputting reactive power according to grid instruction to ensure that PV system meets the performance requirements of Smart Grid and avoid the duplication of investment;
u Aiming at the distributed application, internal integrated lightning protection module, insulation resistance detection module, anti-reverse protection module, dual MPPT maximum power, wireless communications (Wi-Fi) module, the leakage current detection module, thus distributed PV system is simple in structure, easy to install and to maintain;
u The internal protection grade reaches IP67, and more than 95% electrical components use internationally renowned brands, which effectively ensure long-term stable operation of PV systems and can easily cope with -20 Degrees in winter or storms in summer and other harsh natural environment;
u Thinkpower has a secure central server in America, so by inverter’s Wi-Fi function, each set of PV system can at any time and any place do remote monitoring, remote diagnosis and remote software maintenance or upgrades. Truly realize each system around there is an experienced PV system expert;
u The shell is formed by die-casting, so the whole body is high-quality aluminum heat sink. Both from the perspectives of the process structure or thermal performance, Thinkpower series inverters have incomparable advantages;
u With quality assurance, reasonable price and perfect post-sales service system, selecting Thinkpower is equivalent to choosing the highest cost-effective inverter and the most considerate service.
| Model No | T1500TL | T2200TL | T3000TL |
| DC side/Input parameters | |||
| Max. DC power [W] | 1800 | 2500 | 3400 |
| Max. DC voltage [Vdc] | 450 | 500 | 550 |
| Min. System start/Shut down voltage [Vdc] | 150/100 | 150/100 | 150/100 |
| MPPT voltage range[Vdc] | 100~450 | 100~500 | 100~550 |
| Max. input current [A] | 10 | 13 | 15 |
| Number of MPP trackers | 1 | 1 | 1 |
| AC side/output parameters | |||
| Nominal output power [W] | 1500 | 2200 | 3000 |
| Maximum output power [W] | 1650 | 2420 | 3300 |
| Nominal output voltage/range [V] | 208,220,230, 240/180~265 |
208,220,230, 240/180~265 |
208,220,230, 240/180~265 |
| AC grid frequency/range [Hz] | 50,60/±4.5 auto-selection |
50,60/±4.5 auto-selection |
50,60/±4.5 auto-selection |
| Maximum output current [A] | 8 | 12 | 17 |
| AC connection(with PE) | Single phase | Single phase | Single phase |
| Current distortion(THDi) [%] | <1.5 | <1.5 | <1.5 |
| Power factor [%] | More than 99.9 | More than 99.9 | More than 99.9 |
| Efficiency | |||
| Maximum conversion efficiency[%] | 97.3 | 97.4 | 97.5 |
| European efficiency[%] | 97 | 97.1 | 97.2 |
| MPPT efficiency[%] | 99.9 | 99.9 | 99.9 |
| Protection | |||
| DC reverse-polarity protection | yes | yes | yes |
| Short circuit protection | yes | yes | yes |
| Ground fault/residential current monitoring | yes | yes | yes |
| Grid monitoring | yes | yes | yes |
| DC/AC side varistors(thermally protected) | yes | yes | yes |
| General Parameters | |||
| Dimension(L/W/H)[mm] | 375*480*136 | ||
| Weight(kg) | 14.5 15 15.6 | ||
| Embedded DC Switch | Optional | ||
| Night Mode support | Optional | ||
| Night power consumption[W] | < 0.2 | ||
| Isolation type | Transformerless | ||
| Protection degree | IP65 | ||
| Operation temperature[ºC] | -25~60 | ||
| Heat Dissipation | Convection | ||
| Acoustic noise level[dB] | <25 | ||
| Altitude[m] | <2000 without power derating | ||
| Storage temperature[ºC] | -30 ~ 80 | ||
| Real Time Clock module | yes | ||
| LCD Display | Graphic and digital segment | ||
| Communication Interface | Standard WiFi | ||
| Certificates | CE,VDE4105,G83,G59,SAA,CQC | ||
|
Warranty: 5/10/15years yes/optional/optional/optional* More technical characteristics are avaliable on demand and customized. | |||
